Energence
®
Packaged Electric / Electric 26 to 44 kW 50 Hz / Page 12
OPTIONAL CONVENTIONAL TEMPERATURE CONTROL SYSTEMS
Description Catalog No.
ComfortSense
®
8500 Commercial 7 Day Programmable Thermostat
CS8500 7-Day Thermostat No CO Sensing 17G75
With CO Sensing 17G76
Sensors/Accessories ¹ Remote non-adjustable wall-mount 10k 47W37
¹ Remote non-adjustable wall-mount 11k 94L61
Sysbus Network Cable (Yellow) for ComfortSense 8500 and LCS-5030 Wired Room Sensor
Twisted pair 100% shielded communication cable, Red and Black
22 AWG, yellow jacket, rated at 75°C, 300V, Plenum rated
Insulation - Low smoke PVC, NEC, CMP
500 ft. box 27M19
1000 ft. box 94L63
2500 ft. roll 68M25
ComfortSense
®
7500 Commercial 7-Day Programmable Thermostat
CS7500 7-Day Thermostat 17G74
Sensors/Accessories ² Remote non-adjustable wall-mount 20k 47W36
² Remote non-adjustable wall-mount 10k 47W37
Remote non-adjustable discharge air (duct mount) 19L22
Outdoor temperature sensor X2658
ComfortSense
®
3000 Commercial 5-2 Day Programmable Thermostat
CS3000 5-2 Day Thermostat 11Y05
Sensors/Accessories Remote non-adjustable wall mount 10k averaging 47W37
Thermostat wall mounting plate X2659
ComfortSense
®
Non-Programmable Thermostat
CS3000 Non-Programmable Thermostat 51M32
Universal Thermostat Guard with Lock (clear)
Inside Dimensions (H x W) 5 7/8 x 8 3/8 in. 39P21
Wired Room Sensor
LCS-5030 Wired Room Sensor 21L07
1
Up to nine of the same type remote temperature sensors can be connected in parallel.
2
R emote wall-mount sensors can be applied in any of the following combinations:
One Sensor - (1) 47W36, Two Sensors - (2) 47W37, Three Sensors - (2) 47W36 and (1) 47W37
Four Sensors - (4) 47W36, Five Sensors - (3) 47W36 and (2) 47W37
