Energence
®
Packaged Electric / Electric 26 to 44 kW 50 Hz / Page 5
FEATURES AND BENEFITS

Options/Accessories
Factory or Field Installed
Return Air Adaptor Plate

replacement
Installs on return air opening in unit to match return air
opening on existing roof curbs
Also see Accessory Air Resistance table
Factory Installed
Corrosion Protection


AST ElectroFin E-Coat
Meets Mil Spec MIL-P-53084, ASTM B117 Standard
Method Salt Spray Testing
Indoor Corrosion Protection:
Coated coil
Coated reheat coil (Humiditrol
®
)
Painted blower housing
Painted base
Outdoor Corrosion Protection:
Coated coil
Painted outdoor base
Field Installed
Combination Coil/Hail Guards
Heavy gauge steel frame
Painted to match cabinet
Expanded metal mesh protects outdoor coil
Horizontal Discharge Kit

and return air openings for horizontal applications

when economizer is used in horizontal applications
NOTE
with economizer, a separate Horizontal Barometric
Relief Damper with Hood must be ordered
separately for installation in the return air duct
BLOWER
A wide selection of supply air blower options are

Motor
Overload protected
Ball bearings
Belt drive motors are offered on all models and are available
in several different sizes to maximize air performance
Supply Air Blower
Forward curved blades
Double inlet
Blower wheel statically and dynamically balanced
Ball bearings
Adjustable pulley (allows speed change)
Blower assembly slides out of unit for servicing
Ordering Information
Specify motor horsepower and drive kit number when
base unit is ordered
Options/Accessories
Factory Installed
Blower Belt Auto-Tensioner
Provides proper tension to belt drive blower belt without
the need for regular adjustments

ELECTRICAL
SmartWire™ System
Keyed and color-coded wiring connectors prevent
miswiring
Wire coloring scheme is standardized across all models
Each connection is intuitively labeled to make
troubleshooting and servicing quick and easy
Electrical Plugs
Positive connection electrical plugs are used to connect
common accessories or maintenance parts for easy
removal or installation
Options / Accessories
Factory or Field Installed
Electric Heat
Electric heat is CE marked
Helix wound nichrome elements
Individual element limit controls
Wiring harness
Unit fuse block

information
GG
HH
