Packaged Gas / Electric 45.7 to 88 kW - 50 Hz / Page 20
SPECIFICATIONS
General Data Nominal kW (Tons) 70.3 kW 88 kW
Model Number LGH240H4B LGH300S4B
Eciency Type High Standard
Blower Type CAV
(Constant Air Volume)
CAV
(Constant Air Volume)
Cooling
Performance
60.1 (205 000) 71.8 (245 000)
1
58.0 (198 000) 68.6 (234 000)
Rated Air Flow - L/s (cfm) 3020 (6400) 3965 (8400)
16.2 21.9
1
12.2 10.7
2
8.2 7.7
1
IEER (Btuh/Watt) 13.2 11.2
R-410A R-410A
Refrigerant
Charge
Environ™
Circuit 1 2.84 kg (6 lbs. 4 oz.) 2.84 kg (6 lbs. 4 oz.)
Circuit 2 2.78 kg (6 lbs. 2 oz.) 2.55 kg (5 lbs. 10 oz.)
Circuit 3 2.66 kg (5 lbs. 14 oz.) 2.89 kg (6 lbs. 6 oz.)
Circuit 4 2.44 kg (5 lbs. 6 oz.) 2.72 kg (6 lbs. 0 oz.)
Environ™ Coil
With Humiditrol
®
Circuit 1 2.84 kg (6 lbs. 4 oz.) 3.40 kg (7 lbs. 8 oz.)
Circuit 2 2.55 kg (5 lbs. 10 oz.) 2.84 kg (6 lbs. 4 oz.)
Circuit 3 2.21 kg (4 lbs. 14 oz.) 2.78 kg (6 lbs. 2 oz.)
Circuit 4 2.21 kg (4 lbs. 14 oz.) 2.66 kg (5 lbs. 14 oz.)
Coil Option
Circuit 1 4.54 kg (10 lbs. 0 oz.) 4.76 kg (10 lbs. 8 oz.)
Circuit 2 4.54 kg (10 lbs. 0 oz.) 4.53 kg (10 lbs. 0 oz.)
Circuit 3 4.54 kg (10 lbs. 0 oz.) 4.42 kg (9 lbs. 12 oz.)
Circuit 4 3.97 kg (8 lbs. 12 oz.) 4.42 kg (9 lbs. 12 oz.)
With Humiditrol
®
Circuit 1 5.44 kg (12 lbs. 0 oz.) 5.78 kg (12 lbs. 12 oz.)
Circuit 2 5.44 kg (12 lbs. 0 oz.) 5.32 kg (11 lbs. 12 oz.)
Circuit 3 4.54 kg (10 lbs. 0 oz.) 4.42 kg (9 lbs. 12 oz.)
Circuit 4 3.97 kg (8 lbs. 12 oz.) 4.42 kg (9 lbs. 12 oz.)
Gas Heating Options Available See page 21
Compressor Type (number) Scroll (4) Scroll (4)
Outdoor
Coils
Environ™
Fin/Tube
Net face area (total) - m
2 (
sq. ft.)
5.13 (55.2) 5.13 (55.2)
No. of rows Environ™ 1 (2) 1 (2)
Fins per meter (Fins per inch)
906 (23)/787 (20) 787 (20)/787 (20)
Outdoor Coil
Fans
Motor - (No.) W (HP)
(6) 250 (1/3) (6) 250 (1/3)
Motor rev/min
896 896
1490 1490
Diameter - (No.) mm (in.)
(6) 610 (24) (6) 610 (24)
Number of blades
3 3
7866 (16 666) 7866 (16 666)
Indoor Coils
Net face area (total) - m
2
(sq. ft.)
1.99 (21.4) 1.99 (21.4)
9.5 (3/8) 9.5 (3/8)
Number of rows
4 4
Fins per meter (Fins per inch)
551 (14) 551 (14)
Drain connection - No. and size
3
Indoor
Blower
and
Drive
Selection
Nominal Motor kW (HP)
3.7 (5) 3.7 (5)
Maximum usable motor kW (HP)
4.3 (5.75) 4.3 (5.75)
Kit # (rev/min range)
#3 (571-721) #3 (571-721)
#4 (708-871) #4 (708-871)
#5 (788-988) #5 (788-988)
Nominal Motor kW (HP)
5.6 (7.5) 5.6 (7.5)
Maximum usable motor kW (HP)
6.4 (8.6) 6.4 (8.6)
Kit # (rev/min range)
#6 (708-871) #6 (708-871)
#7 (788-988) #7 (788-988)
#8 (871-1071) #8 (871-1071)
Nominal Motor kW (HP)
7.5 (10) 7.5 (10)
Maximum usable motor kW (HP)
8.6 (11.5) 8.6 (11.5)
Kit # (rev/min range)
#7 (788-988) #7 (788-988)
#10 (871-1071) #10 (871-1071)
#11 (945-1138) #11 (945-1138)
Blower wheel nominal diameter x width - mm (in.)
(2) 381 x 381 (15 x 15)
Filters
Fiberglass, disposable - (6) 610 x 610 x 51 (24 x 24 x 2)
Electrical Characteristics 380/420V - 50 hertz - 3 phase with neutral (No neutral on CE marked models)
1
minimum external duct static pressure while operating at rated voltage and air volumes.
2
3
service factor limitations outlined on the motor nameplate.
