Energence
®
Packaged Gas / Electric 45.7 to 88 kW - 50 Hz / Page 34
ELECTRICAL DATA
LGH156H LGH180H LGH210H LGH240H LGH300S
1
Voltage - 50hz - 3 phase with neutral 380/420V 380/420V 380/420V 380/420V 380/420V
Compressor 1
Rated Load Amps
6.3
6.3
7.8
6.3
8
Locked Rotor Amps
55
55
51.5
55
67.1
Compressor 2
Rated Load Amps
6.3
6.3
7.8
6.3
8
Locked Rotor Amps
55
55
51.5
55
67.1
Compressor 3
Rated Load Amps
6.3
6.3
8
6.3
10.6
Locked Rotor Amps
55
55
67.1
55
74
Compressor 4
Rated Load Amps - - - - - - - - - 6.3
10.6
Locked Rotor Amps - - - - - - - - - 55
74
Outdoor Fan
Motors
Number of motors 3 4 6 6 6
Full Load Amps 1.3 1.3 1.3 1.3 1.3
(total) (3.9) (5.2) (7.8) (7.8) (7.8)
Power Exhaust
With (2) 0.25 kW
Full Load Amps 1.3 1.3 1.3 1.3 1.3
(total) (2.6) (2.6) (2.6) (2.6) (2.6)
Indoor Blower
Motor
kW 1.5 2.2 3.7 2.2 3.7 5.6 2.2 3.7 5.6 3.7 5.6 7.5 3.7 5.6 7.5
Full Load Amps 3.6 5.3 8.2 5.3 8.2 11.7 5.3 8.2 11.7 8.2 11.7 16 8 12 16
2
Maximum
Overcurrent
Protection
30 35 40
35 40 50
45 45 50
50 50 60
60 70 80
With (2) 0.25 kW
Power Exhaust
35 35 40
35 45 50
45 50 60
50 60 70
60 70 80
3
Minimum
Circuit
Ampacity
28 30 34
31 35 39
39 42 47
44 48 54
56 60 66
With (2) 0.25 kW
Power Exhaust
31 33 36
34 37 42
42 44 49
46 51 56
59 66 68
1
2
3
Refer to local codes to determine wire, fuse and disconnect size requirements.
