Lennox Energence LGH User Manual

Energence
®
Packaged Gas / Electric 45.7 to 88 kW - 50 Hz / Page 22
RATINGS

45.7 kW - LGH156H4 (1ST STAGE)
Entering
Wet
Bulb
Temper-
ature
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
18.3°C 23.9°C 29.4°C 35°C
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Dry Bulb Dry Bulb Dry Bulb Dry Bulb
L/s kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C

1965 28.6 3.87 0.71 0.85 0.99 26.6 4.38 0.71 0.86 1.00 24.6 4.94 0.72 0.88 1.00 22.5 5.57 0.72 0.91 1.00
2455 30.3 3.9 0.76 0.93 1.00 28.2 4.41 0.77 0.95 1.00 26.1 4.97 0.78 0.97 1.00 24.0 5.60 0.79 0.99 1.00
2945 31.6 3.93 0.81 0.99 1.00 29.6 4.44 0.83 1.00 1.00 27.6 5.00 0.85 1.00 1.00 25.6 5.64 0.87 1.00 1.00

1965 30.7 3.91 0.56 0.68 0.81 28.7 4.42 0.55 0.69 0.83 26.6 4.98 0.54 0.69 0.84 24.4 5.61 0.54 0.70 0.87
2455 32.4 3.95 0.59 0.74 0.90 30.3 4.45 0.59 0.75 0.92 28.1 5.01 0.59 0.76 0.94 25.9 5.64 0.59 0.77 0.96
2945 33.8 3.98 0.62 0.79 0.97 31.5 4.48 0.62 0.81 0.99 29.2 5.04 0.63 0.82 0.99 26.9 5.67 0.63 0.85 1.00

1965 32.7 3.95 0.42 0.55 0.66 30.6 4.46 0.41 0.54 0.67 28.5 5.02 0.39 0.54 0.67 26.3 5.65 0.37 0.53 0.68
2455 34.6 3.99 0.44 0.58 0.72 32.4 4.50 0.42 0.58 0.73 30.1 5.06 0.41 0.58 0.74 27.9 5.69 0.40 0.58 0.75
2945 35.9 4.03 0.45 0.62 0.77 33.7 4.53 0.44 0.62 0.78 31.3 5.09 0.43 0.62 0.80 28.9 5.72 0.42 0.63 0.82
45.7 kW - LGH156H4 (2ND STAGE)
Entering
Wet
Bulb
Temper-
ature
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
26.7°C 35°C 43.3°C 46°C
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Dry Bulb Dry Bulb Dry Bulb Dry Bulb
L/s kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C

1965 39.3 7.04 0.74 0.91 1.00 34.6 8.43 0.76 0.95 1.00 29.7 10.11 0.78 0.99 1.00 28.2 10.73 .79 .99 1.00
2455 41.6 7.09 0.81 0.99 1.00 37.1 8.48 0.83 1.00 1.00 32.4 10.18 0.87 1.00 1.00 30.9 10.79 .89 1.00 1.00
2945 44.0 7.15 0.87 1.00 1.00 39.4 8.54 0.91 1.00 1.00 34.6 10.24 0.96 1.00 1.00 33.0 10.85 .97 1.00 1.00

1965 42.3 7.11 0.57 0.72 0.87 37.5 8.49 0.56 0.74 0.91 32.3 10.18 0.56 0.75 0.95 30.7 10.79 .55 .77 .97
2455 44.6 7.16 0.61 0.79 0.96 39.5 8.54 0.61 0.81 0.99 34.1 10.23 0.61 0.85 1.00 32.4 10.83 .62 .87 1.00
2945 46.2 7.2 0.65 0.85 1.00 40.9 8.58 0.66 0.89 1.00 35.4 10.26 0.67 0.93 1.00 33.6 10.87 .68 .95 1.00

1965 45.3 7.17 0.41 0.56 0.70 40.3 8.56 0.39 0.56 0.71 35.1 10.25 0.37 0.55 0.73 33.4 10.86 .35 .55 .75
2455 47.7 7.23 0.43 0.60 0.77 42.5 8.62 0.41 0.61 0.79 37.0 10.30 0.39 0.61 0.82 35.2 10.91 .38 .62 .84
2945 49.5 7.28 0.45 0.64 0.83 44.0 8.66 0.43 0.65 0.86 38.3 10.34 0.42 0.67 0.91 36.5 10.95 .41 .68 .93
Entering
Wet
Bulb
Temper-
ature
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
48°C 50°C 51.7°C
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Dry Bulb Dry Bulb Dry Bulb
L/s kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C

1965 27.0 11.23 0.79 1.00 1.00 25.9 11.74 0.81 1.00 1.00 25.0 12.20 0.81 1.00 1.00
2455 29.7 11.30 0.90 1.00 1.00 28.5 11.81 0.92 1.00 1.00 27.5 12.27 0.93 1.00 1.00
2945 31.8 11.35 0.98 1.00 1.00 30.5 11.87 0.99 1.00 1.00 29.5 12.32 1.00 1.00 1.00

1965 29.4 11.29 0.55 0.77 0.98 28.1 11.80 0.55 0.78 0.99 27.0 12.25 0.55 0.79 0.99
2455 31.0 11.33 0.62 0.87 1.00 29.7 11.84 0.62 0.89 1.00 28.5 12.30 0.62 0.90 1.00
2945 32.2 11.37 0.68 0.96 1.00 30.9 11.88 0.68 0.98 1.00 29.7 12.33 0.69 0.99 1.00

1965 32.0 11.36 0.34 0.55 0.75 30.7 11.87 0.33 0.55 0.76 29.6 12.32 0.32 0.55 0.76
2455 33.8 11.41 0.38 0.62 0.85 32.4 11.92 0.37 0.62 0.86 31.2 12.37 0.36 0.62 0.87
2945 35.0 11.45 0.41 0.68 0.94 33.6 11.96 0.40 0.69 0.95 32.4 12.41 0.40 0.69 0.96
