Page 98 - IOM / ROOF-TOP FLEXY™ Series
ELECTRICAL DATA
FXA / FXK = Heat pump rooftop
Electric heater TRIAC
Hot water coil
Heat pump
-
Economiser
-
-
Firestat
Smoke detector
Advanced control pack (FC : cooling- FH : heat pump)
Digital console KP02
Consoles KP17
Hygiene probe
Air sock control
Dry contact kit (KP12.2)
RS232 KP14
CL06
KP07
-
-
Remote set point (KP05)
Climalink/Climalook
KP12.3 (TCB)
KP12.4 (Adaptvision)
01020304.10506070809
10FH
11121314151617181920212223242526
-
All fresh air
DIAGRAM REFERENCE LEGEND
+A0 Climatic controller
+A1+A2 Condensation group 1 / Condensation group 2
+A3+A4 Condenser 1 /Condenser 2
-A1
-B1 External air thermostat
-B2 Smoke detection head
-B3 RC circuit
-B4-B5 Gas manifold ionisation probe
-B6-B7 Gas manifold ignition electrode
-B11 Water flow rate controller
-B13 Clogged air filter pressure switch / air flow rate
-B14 Hot water battery antifreeze thermostat
-B15 Hot water battery antifreeze thermostat
-B16 Fire thermostat
-B17-B18 Gas manifold smoke minimum gas pressure switch
-B19-B20 Blower fan motor -MS1-MS2 stoptherme
-B21-B22 Gas manifold extraction air pressure switch
-B23-B24 Extraction fan motor -ME1-ME2 stoptherme
-B25-B26 Electric battery -E1-E2 safety klixon
-B27 Electric battery -E3 safety klixon
-B29-B30 Gas manifold air flow rate safety klixon
-B32-B33 Gas manifold flashback safety klixon
-B41-B42 Compressor -MG1-MG2 high pressure safety switch
-B43-B44 Compressor -MG3-MG4 high pressure switch
-B45-B46 Gas manifold 1 / gas manifold 2 regulation klixon
-B51-B52 Compressor -MG1-MG2 low pressure safety switch
-B53-B54 Compressor-MG3-MG4 low pressure safety switch
-B61-B62 Compressor -MG1-MG2 high pressure control switch
-B63-B64 Compressor -MG3-MG4 high pressure control switch
-B71-B72 Condenser -MC1-MC2 fan motor stoptherme
-B73-B74 Condenser -MC3-MC4 fan motor stoptherme
-B81-B82 Scroll compressor -MG1-MG2 protection module
-B83-B84 Scroll compressor -MG3-MG4 protection module
-B91-B92 Pressure switch 4 / 20ma compressor -MG1-MG2
-B93-B94 Pressure switch 4 / 20ma compressor -MG3-MG4
BCD Condense battery
BEC Hot water battery
BEG Chilled water battery
BEV Evaporator battery
-BG10 Hygiene probe
-BH10 Regulation hygrometry probe
-BH11 External hygrometry probe
-BT10 Regulation temperature probe
-BT11 External temperature probe
-BT12 Blower temperature probe
-BT13 Cold water temperature probe
-BT14 Condenser 1 speed regulation temperature probe
-BT15 Condenser 2 speed regulation temperature probe
-BT16 Heat exchanger water outlet antifreeze probe
-BT17 Mixture probe
-BT21-BT22 Compressor 1-2 antifrost temperature probe
-BT23-BT24 Compressor 3-4 antifrost temperature probe
-BT25 Free temperature
-BT91-BT92 Defrost temperature sensor compressor 1-2
-BT93-BT94 Defrost temperature sensor compressor 3-4
-BTP1-2 Compressor -MG1-MG2 accumulator
-BTP3-4 Compressor -MG3-MG4 accumulator
CL06.2 JBUS
DT Thermostatic holder
-EEH Horizontal water heat exchanger
EEV Vertical water heat exchanger
-E1-E2 Heater -E1-E2
-E3 Heater -E3
-E4 Vapour humidifier -E4
-E7-E8 Antifreeze heater cords hot water battery
-E9-E10 Antifreeze heater cords
-E11 Smoke detector printed circuit
-E12 Humidifier -E4 level solenoid valve
-E13 Water leak electrode
-E14 Burner control box
-E15 Vapour humidifier -E4 printed circuit
