Page 96 - IOM / ROOF-TOP FLEXY™ Series

ELECTRICAL DATA

The power cable should be connected to the main isolating

switch and is fed from the underside of the unit into the

electrical panel.

Refer to the general arrangement drawings in the

documentation to locate the exact entry position.

The power cable sizes must be calculated with reference to

the electrical characteristics of your machine.

We are unable to state the cross sectional area of the cable

as it is directly related to the type of cable you are using, the

distance separating the equipment from the source but also

various factors relating to the cable fitting.

In the following pages you will find references to electrical

diagrams which will allow you to select the wiring for your

equipment.

As the diagrams are valid for the entire range, they will refer

to items not included in your scope of supply.

FUNCTIONS

FCA / FCK = Cooling only unit

01020304.10506070809

10FC

11121314151617181920212223242526

Electric heater TRIAC

Hot water coil

Economiser

Extraction fan

All fresh air

Firestat

Smoke detector

Advanced control pack (FC : cooling - FH : heat pump)

Digital console KP02

Consoles KP07 or KP17

Hygiene probe

Air sock control

Dry contact kit (KP12.2)

RS232 KP14

CL06

KP07

Pump

Low ambient kit

Remote set point (KP05)

KP12.3 (TCB)

KP12.4 (Adaptvision)

Climalink/Climalook

FDA / FDK = Cooling only unit

01020304.204.304.4050607
