INSTALLATION ON A ROOFMOUNTING FRAME
As levels are adjustable, observe the following
recommendations for correct installation of the equipment.
Above all, ensure that all the adjustable returns are
facing outward (1 - figure 6).
They are usually turned inside-out for transport.
Place the roof mounting frame on the trimmer beam by
first lining up the inlet and then the outlet. (2 - figure 7).
After levelling the frame, fix the surface flaps onto the
trimmer.
1
Figure 6
Figure 7
Figure 8
