IOM / ROOF-TOP FLEXY™ Series - Page 99
-E16 Printed circuit 0/10V vapour humidifier -E4
-E20 CPU card KP01
-E21 ON-OFF input card KP03
-E22 ON-OFF input card KP08,1
-E23 Analog output card KP04,1
-E24 Analog output card KP04,2
-E25 Analog output card KP04,3
-E26 Analog output card KP04,4
-E27 ON-OFF input card KP08,2
-E28 Input card 4 /20 mA KP05,1
-E29.1.2 Input output card KP12
-E30 Digital console KP02 ou KP17
-E31 Graphic console KP07
-E32 Interface
-E51-E52 Compressor -MG1-MG2 housing resistance
-E53-E54 Compressor -MG3-MG4 housing resistance
FCO Water circuit humidifier
FD Dehumidifier filter
FDB Bottle dehumidifier filter
FDW Double flow dehumidifier filter
-F1 Secondary circuit -T1 128VA / 24V protection fuse
-F2 Secondary circuit -T1 30VA / 12V protection fuse
-F3 Secondary circuit -T1 6VA / 12V protection fuse
-F4 Secondary circuit -T1 36VA / 24V protection fuse
-KA31-KA32 Gas burner fault relay
-KA41-KA42 Gas burner fault relay
-KA1-KA2 Relay
-KA3 Smoke fault relay
-KA4 PV/GV relay
-KA9 External temperature relay +5°
-KE1-KE2 Heater -E1-E2 contactor
-KE3 Heater -E3 contactor
-KE4 Vapour humidifier -E4 contactor
-KM1-KM2 Blower fan motor -MS1-MS2 contactor
-KM3 Blower fn motor low speed contactor
-KM4 Star coupling contactor
-KM5-KM6 Extraction fan motor -ME1-ME2 contactor
-KM7 Extraction fan motor low speed contactor
-KM8 Star coupling contactor+E40
-KM9-KM10 Condenser 1 / condenser 2 fan motor contactor
-KM11-KM12 Compressor -MG1-MG2 contactor
-KM13-KM14 Compressor -MG3-MG4 contactor
-KM15 Condenser 2 fan motor contactor
-KM20 Circulation pump -MP1 contactor
-KM21-KM22 Gas manifold 1 - gas manifold 2 contactor
-
KM91-KM101
Low ambient contactor
-KT1.2 Timing relay
-MC1,2 Condenser -MC1-MC2 fan motor
-MC3,4 Condenser -MC3-MC4 fan motor
-ME1-ME2 Extraction fan motor -ME1-ME2 contactor
-ME3-ME4 Extraction fan motor -ME3-ME4
-MG1-MG2 Compressor -MG1-MG2 contactor
-MG3-MG4 Compressor -MG3-MG4 contactor
-MP1 Circulation pump motor
-MR1 Economiser damper motor
-MR2 Blower damper motor
-MR3 Fresh air damper motor
-MR4 Extraction damper motor
-MR5 Recycler air damper motor
-MS1-MS2 Blower fan motor -MS1-MS2
-Q1-Q2 Blower fan motor -MS1-MS2 protection
-Q5-Q6 Extraction fan motor -ME1-ME2 protection
-Q9 Condenser -MC1-MC2 fan motor protection
-Q10 Condenser -MC3-MC4 fan motor protection
-Q11-Q12 Compressor -MG1-MG2 protection
-Q13-Q14 Compressor -MG3-MG4 protection
-Q15 Condenser -MC2 fan motor protection
-Q20 Circulation pump -MP1 protection
-Q25 Housing resistance protection
-QF1 Primary circuit protection -T1
-QF2 Primary circuit protection -T3
-QF3 Secondary circuit protection -T3
-QF4 Primary circuit protection -T4
-QG Main switch
-QG1-QG2 Condenser 1 / condenser 2 main switch
-QE1-QE2 Heater -E1-E2 protection
-QE3 Heater -E3 protection
-RL Liquid reservoir
-SAT Check valve
-SA1 Humidifier -E4 on/off switch
-SA2 Humidifier -E4 drain switch
-SB1 Emergency stop
-T1 Control circuit transformer 400v / 24v
-T2 Power supply transformer 400v / 12v / 12v / 24v
-T3 Burner power supply transformer 400 / 230v
-T4 Power supply transformer -dad4485 400 / 230v
-TCB control thermostat
-TI4 Humidifier -E4 current transformer
UF Cooling unit
UT Air treatment unit
U1 Interface
VAM Manual check valve
VL Liquid indicator
VRM Manual control valve
-V1 Electric battery static contactor
-V2 Electric battery static contactor
V2VP Pressure switched 2-way valve
V3VP Pressure switched 3-way valve
-Y1 Gas manifold N1 reset electromagnet
-Y2 Gas manofold N2 reset electromagnet
-YR Humidifier -E4 filling solenoid valve
-YV Humidifier -E4 drain solenoid valve
-YV1 Chilled water 3-way valve
-YV2 Hot water 3-way valve
-YV11-YV12 Compressor -MG1-MG2 cycle reversal valve
-YV13-YV14 Compressor -MG3-MG4 cycle reversal valve
-YV31-YV32 Burner gas solenoid valve
-YV41-YV42 Gas manifold safety solenoid valve
-YV51-YV52 Gas manifold main solenoid valve
-YV61 Compressor -MG1 hot gas injection solenoid valve
-YV71-YV72 Compressor -MG1-MG2 liquid solenoid valve
-Z* Capacity resistance circuit
ELECTRICAL DATA
