IOM / ROOF-TOP FLEXY™ Series - Page 71
Configuration table LF20
USING THE KP02 MAINTENANCE CONTROL DISPLAY
Switches on KP01
1 = on ....................... Option : pressure pick-up on air 500 pa (on FLEXY™ off = sensor 1000 pa)
2 = on | 3 = off ................... Option : hot water coil
2 = off | 3 = on ................... Option : electrical heater
2 = on | 3 = on ...................Option : gas burner
4 = on ....................... Option : cycle reversing valve, compressors (heat pump)
5 = on ....................... Option : heating of great power / or / pump (except freezing of the hot water coil)
6 = on ....................... Option : fresh air, economiser
7 = on ....................... Option : fresh air, all fresh air
8 = on ....................... Option : KP02 / KP17
F.A050 11
F.A060 12
F.A070 13
F.A085 14
F.A100 15
F.A120 16
F.A140 17
F.A160 18
F.A190 19
FXA025 20
FXA030 21
FXA035 22
FXA040 23
FXA055 24
FXA070 25
FXA085 26
FXA100 27
FXA110 28
FXA140 29
FXA170 30
F.K050 111
F.K060 112
F.K070 113
F.K085 114
F.K100 115
F.K120 116
F.K140 117
F.K160 118
F.K190 119
FXK025 120
FXK030 121
FXK035 122
FXK040 123
FXK055 124
FXK070 125
FXK085 126
FXK100 127
FXK110 128
FXK140 129
FXK170 130
