ENERGY RECOVERY INSTALLATION
FLEXYII_WSHP-IOM-0909-E Page 42
To check the wiring, please refer to Rooftop and Recovery Module electrical diagram.
Then connect the power cable from the module to the rooftop, and the t-lan to the
Climatic50 (or the BE50 if presents in electrical rooftop panel)
Recovery Module Connection
Exctraction Roofcurb Connection
Be careful: Check connections and connect male connections to good
female one.
Roofcurb and recovery module connectors are the same.
Actuator Roofcurb Connection
To Next Page
