Lennox G60UHV User Manual

Page 2
SPECIFICATIONS
Gas
Heating
Performance
ModelNo. G60UHV−36A−070 G60UHV−36B−090 G60UHV−60C−090
Low NOx Model No. G60UHV−36A−070X − − − G60UHV−60C−090X
Input− Btuh (kW) low fire 45,000 (13.2) 60,000 (17.6) 60,000 (17.6)
Output− Btuh (kW) low fire 36,000 (10.5) 48,000 (14.1) 48,000 (14.1)
Input− Btuh (kW) high fire 66,000 (19.3) 88,000 (5.8) 88,000 (25.8)
Output− Btuh (kW) high fire 54,000 (15.8) 72,000 (21.0) 72,000 (21.1)
AFUE 80.0% 80.0% 80.0%
California Seasonal Efficiency 77.2% 77.1% 76.8%
Highstatic(CSA)− in.w.g. (Pa) .80 (200) .80 (200) .80 (200)
Flue connection − in. (mm) round 4 (102) 4 (102) 4 (102)
GaspipesizeIPS− in. (mm) 1/2 (12.7) 1/2 (12.7) 1/2 (12.7)
Temperature rise range − F (C) low fire 20 − 50 (11 − 28) 20 − 50 (11 − 28) 15 − 45 (8 − 25)
Temperature rise range − F (C) high fire 40 − 70 (22 − 39) 40 − 70 (22 − 39) 30 − 60 (17 − 33)
Indoor
Blower
Wheelnominaldiameter xwidth −in. (mm) 10 x 8 (254 x 203) 10 x 8 (254 x 203) 11−1/2 x 10 (292 x 254)
Motoroutput − hp (W) 1/2 (373) 1/2 (373) 1 (746)
Tons(kW) ofadd-oncooling 2 − 3 (7.0 − 10.6) 2 − 3 (7.0 − 10.6) 4 − 5 (14.1 − 17.6)
Shippingweight − 1 package 137 (62) 154 (70) 172 (78)
Matching Coils Up−flow cased C33−18A−2F,
C33−24A−2F,
C33−30A−2F,
C33−36A−2F,
C33−38A−2F
C33−24B−2F,
C33−30B−2F,
C33−36B−2F,
C33−38B−2F,
C33−42B−2F,
C33−48B−2F
C33−36C−2F,
C33−48C−2F,
C33−50/60C−2F,
Horizontal CH33−18A−2F,
CH33−24/30A−2F,
CH33−36A−2F
CH33−36B−2F,
CH33−42B−2F,
CH33−44/48B−2F
CH33−36C−2F,
CH33−48C−2F,
CH33−50/60C−2F
Electricalcharacteristics 120 volts − 60 hertz − 1 phase (less than 12 amps)
OPTIONAL ACCESSORIES − MUST BE ORDERED EXTRA
 Air Filter and Rack Kit
Number and size of filters
Horizontal (end) 87L95 − (1) 14 x 25 x 1 in.
(356 x 635 x 25 mm)
87L96 − (1) 18 x 25 x 1 in.
(457 x 635 x 25 mm)
87L97 − (1) 20 x 25 x 1 in.
(508 x 635 x 25 mm)
Side Return Single (44J22) or Ten Pack (66K63) − (1) 16 x 25 x 1 in. (406 x 635 x 25 mm)
EZ Filter Base Catalog Number − Shipping Weight 73P55 − 6 lbs. (3 kg) 73P56 − 7 lbs. (3 kg) 73P57 − 8 lbs. (4 kg)
Dimensions − H x W x D 4 x 14−1/4 x 28−5/8 in.
(102 x 362 x 727 mm)
4 x 17−5/8 x 28−5/8 in.
(102 x 448 x 727 mm)
4 x 21−5/8 x 28−5/8 in.
(102 x 549 x 727 mm)
Number and size of filter (field provided) 14 x 25 x 1 in. (356 x
635 x 25 mm)
16 x 25 x 1 in. (406 x
635 x 25 mm)
20 x 25 x 1 in. (508 x
635 x25 mm)
CCB1 Efficiency Plust Humidity Control System 35H00 35H00 35H00
High Altitude Pressure Switch Kit See Page 7
Horizontal Support Frame Kit − Shipping Weight 56J18 − 18 lbs. (8 kg) 56J18 − 18 lbs. (8 kg) 56J18 − 18 lbs. (8 kg)
LPG/Propane Kit See Page 7
RAB Return Air Base − − − − − − RAB60C (12M71)
Vent Adaptor − 6 in. 152 (mm) connection size 18M79 − 2 lbs. (1 kg) 18M79 − 2 lbs. (1 kg) 18M79 − 2 lbs. (1 kg)
Annual Fuel Utilization Efficiency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized furnaces.
NOTE − Filters and provisions for mounting are not furnished and must be field provided.
 The same C33 uncased models match the furnaces shown but require an optional adaptor base or field fabricated transition. See C33 coil bulletin for additional information.
 Cleanable polyurethane frame type filter.
 Not for use with RAB Return Air Base or with 60C and 60D size units with 2nd stage heating air flow requirements of 1800 cfm (850 L/s) or greater. See Blower Performance
Tables for additional information.

Lennox G60UHV Specifications

General

Heating Stages	Two-Stage
Blower Motor	Variable Speed
Fuel Type	Natural Gas
Ignition System	Hot Surface Ignition
Configuration	Upflow/Horizontal
Heating Capacity	44, 000 to 132, 000 BTU/h
Warranty	Limited Lifetime Heat Exchanger Warranty, 5-Year Limited Warranty on covered components
