SPECIFICATIONS
Gas
ModelNo. G61MP−48C−110 G61MP−60C−110 G61MP−60D−135
Heating
High Fire
Input− Btuh (kW) 110,000 (32.2) 110,000 (32.2) 132,000 (38.7)
er
ormance
Output− Btuh (kW) 104,000 (30.5) 104,000 (30.5) 124,000 (36.3)
Temperature rise range − _F (_C) 45 − 75 (25 − 42) 35 − 65 (21 − 39) 40 − 70 (24 − 42)
Low Fire
Input− Btuh (kW) 75,000 (22.0) 75,000 (22.0) 90,000 (26.4)
Output− Btuh (kW) 72,000 (21.1) 72,000 (21.1) 86,000 (25.2)
Temperature rise range − _F (_C) 30 − 60 (18 − 36) 25 − 55 (14 − 31) 30 − 60 (18 − 36)
1
AFUE 94.1% 94.1% 94.1%
California Seasonal Efficiency 88.4% 87.0% 87.7%
Highstatic(CSA)− in.w.g. (Pa) 0.5 0.5 0.5
Connections
2
Intake Pipe (PVC) 2 2 3
in.
2
Exhaust Pipe (PVC) 2 2 3
Condensate Drain Trap (PVC pipe) − i.d. 1/2 1/2 1/2
with field supplied (PVC coupling) − o.d. 3/4 3/4 3/4
hose with hose clamp − i.d. x o.d. 1−1/4 x 1 1−1/4 x 1 1−1/4 x 1
GaspipesizeIPS 1/2 1/2 1/2
Indoor
Wheelnominaldiameter xwidth −in. (mm) 10 x 10 (254 x 254) 11−1/2 x 10 (292 x 229) 11−1/2 x 10 (292 x 229)
Blower
Motoroutput − hp (W) 1/2 (373) 1 (746) 1 (746)
Tons(kW) ofadd-oncooling 3 − 4 (10.5 − 14.0) 4 − 5 (14.0 − 17.5) 4 − 5 (14.0 − 17.5)
ShippingData lbs. (kg) − 1 package 178 (81) 186 (84) 206 (93)
Electricalcharacteristics 120 volts − 60 hertz − 1 phase (less than 12 amps)
OPTIONAL ACCESSORIES − MUST BE ORDERED EXTRA
3,
4
Air Filter and Rack Kit −
Size of filter
Horizontal (end) 87L97 − 20 x 25 x 1 in. (508 x 635 x 25 mm) 87L98 − 25 x 25 x 1 in.
(635 x 635 x 25 mm)
Side Return
5
Single 44J22 or Ten Pack (66K63) − (1) 16 x 25 x 1 in. (406 x 635 x 25 mm)
Condensate Drain Heat
6 ft. (1.8 m) 26K68 26K68 26K68
Cable
24 ft. (7.3 m) 26K69 26K69 26K69
50 ft. (15.2 m) 26K70 26K70 26K70
Heat Cable Tape
Fiberglass − 1/2 in. (38 mm) x 66 ft. (20 m)
39G04 39G04 39G04
Aluminum foil − 2 in. (25 mm) x 60 ft. (18 m)
39G03 39G03 39G03
4
EZ Filter Base
Catalog Number − Shipping Weight 73P57 − 8 lbs. (4 kg) 73P58 − 10 lbs. (5 kg) 73P58 − 10 lbs. (5 kg)
Dimensions − H x W x D − in. (mm) 4 x 21−5/8 x 28−5/8
(102 x 549 x 727)
4 x 24−5/8 x 28−5/8
(102 x 625 x 727)
4 x 24−5/8 x 28−5/8
(102 x 625 x 727)
Size of field provided filter − in. (mm) 20 x 25 x 1
(508 x 635 x 25)
24 x 24 x 1
(610 x 610 x 25)
24 x 24 x 1
(610 x 610 x 25)
Down−Flow Additive Base 11M61 11M61 11M62
5
High Altitude Orifice Kit − Natural Gas Only 59M16 59M16 59M16
6
High Altitude Pressure Switch Kit − Order two each
4501−10,000 ft. (1372−3048 m)
− − − − − − 56M93
Horizontal Support Frame Kit − Ship. Weight − lbs. (kg) 56J18 − 18 (8) 56J18 − 18 (8) 56J18 − 18 (8)
LPG/Propane Kit 0−7500 ft. (0−2286 m) 59M13 59M13 59M13
7501−10,000ft. (2286−3048m) 59M14 59M14 59M14
Natural to LPG/Propane Kit 59M87 59M87 59M87
RAB Return Air Base − − − − RAB60C (12M71) RAB60D (12M72)
7
Termination Kits −
Concentric
2 inch (51 mm) 33K97 33K97 − − −
Direct Vent
Roof/Wall
3 inch (76 mm) 60L46 60L46 60L46
Wall Close−Coupled 3 inch (76 mm) 44J40 44J40 44J40
7,8
Termination Kits
Roof
2 inch (51 mm) 15F75 15F75 − − −
Direct Vent or Non−
3 inch (76 mm) 44J41 44J41 44J41
Wall Ring Kit 2 inch (51 mm) 15F74 15F74
9
15F74
NOTE − Filters and provisions for mounting are not furnished and must be field provided.
1
Annual Fuel Utilization Efficiency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized furnaces.
2
Determine from venting tables proper exhaust pipe size and termination kit required.
3
Cleanable polyurethane frame type filter.
4
Not for use with RAB Return Air Base or with 60C and 60D size units with air flow requirements of 1800 cfm (850 L/s) or greater. See Blower Performance tables for additional
information.
5
Required for proper operation at altitudes from 7501 to 10,000 ft. (2286 to 3048 m).
6
Required for proper operation at altitudes over 4500 ft. (1370 m).
7
See Installation Instructions for specific venting information.
8
Kits contain enough parts for two, non−direct vent installations.
9
Non−direct vent applications only.
