G61MP PARTS ARRANGEMENT
FIGURE 1
TOP CAP
CABINET
BURNER BOX
ASSEMBLY
SIGHT
GLASS
DuralokPlus
TM
HEAT EXCHANGER
ASSEMBLY
CONDENSER COIL
CONTROL BOX
DOOR
INTERLOCK
SWITCH
COLD HEADER
(COLLECTOR)
BOX
COMBUSTION AIR
INDUCER
BLOWER
ACCESS
DOOR
BURNER
ACCESS
PANEL
FLUE
COLLAR
COMBUSTION
AIR PROVE PROVE
SWITCHES*
PRIMARY LIMIT
WARM HEADER
(COLLECTOR)
BOX
GAS VALVE
AND MANIFOLD
SECONDARY
LIMITS (2)
BLOWER
ASSEMBLY
*G61MP−090 shown.
G61MP−045 and −070
are equipped with
two switches.
