Page 47

Field Wiring Applications (Continued)

Jumper Settings (See figure 4)

Thermostat

E20

W915

Y1 to Y2

Wiring Connections

FM21 Heat Pump / 1

Cool

SINGLE Leave Installed

CONTROL

TERM. STRIP

FM21

75VA, 24V

TRANSFORMER*

*Disconnect existing

furnace transformer and re-

place with 75VA, 24V trans-

former if defrost option to be

used.

NOTE − Wiring connections to

outdoor unit and thermostat

made at FM21 control board

per FM21 instructions.

NOTE −

Cut Y1/Y2 jumper

for two−stage

cooling.
