Lennox LGH480 User Manual

Page 39
507232-04 7/2017
TABLE 15
MENU INTERFACE (LEVEL 1 - SETTINGS) - T (TEMPERATURE ECONOMIZER)
Level 2
Level 3
Level 4 Level 5
USE THE ADJUST AND SET VALUES ARROWS
TO SCROLL UP OR DOWN FOR SELECTION
OPTIONS.
RTU OPTION DAMPER
ECONOMIZER TEMP ECON TYPE = TEMPERATURE OFFSET OR TEMPERATURE SETPT
ECONOMIZER
OAT SETPOINT = XX.X F
FREE COOLING
SUPPLY AIR SETPOINT = XX F
MIN DAMPER POSITION
BLOWER ON HIGH = X.X %
MIN DAMPER POSITION
BLOWER ON LOW = X.X %
DEMAND CONTROL VENT
DAMPER START OPEN = XXXX.X PPM
DEMAND CONTROL VENT
DAMPER FULL OPEN = XXXX.X PPM
DEMAND CONTROL VENT
DAMPER MAX OPENING = XXX.X%
FRESH AIR HEATING
ENABLE FAH = YES OR
NO
FRESH AIR HEATING FAH SETPOINT = XX F
FRESH AIR COOLING
ENABLE AFC = YES OR
NO
FRESH AIR COOLING AFC SETPOINT = XX F
TABLE 16
MENU INTERFACE (LEVEL 1 - SETTINGS) - G (GLOBAL ECONOMIZER)
Level 2
Level 3
Level 4 Level 5
USE THE ADJUST AND SET VALUES ARROWS
TO SCROLL UP OR DOWN FOR SELECTION
OPTIONS.
RTU OPTION DAMPER
FREE COOLING
SUPPLY AIR SETPOINT = XX F
MIN DAMPER POSITION
BLOWER ON HIGH = X.X %
MIN DAMPER POSITION
BLOWER ON LOW = X.X %
DEMAND CONTROL VENT
DAMPER START OPEN = XXXX.X PPM
DEMAND CONTROL VENT
DAMPER FULL OPEN = XXXX.X PPM
DEMAND CONTROL VENT
DAMPER MAX OPENING = XXX.X%
FRESH AIR HEATING
ENABLE FAH = YES OR
NO
FRESH AIR HEATING FAH SETPOINT = XX F
FRESH AIR COOLING
ENABLE AFC = YES OR
NO
FRESH AIR COOLING AFC SETPOINT = XX F
