LGH/LCH420, 480, 540, 600
TABLE 17
MENU INTERFACE (LEVEL 1 - SETTINGS) - S (SINGLE ENTHALPY)
Level 2
Level 3
Level 4
USE THE ADJUST AND SET VALUES ARROWS TO SCROLL UP OR
DOWN FOR SELECTION OPTIONS.
RTU OPTION DAMPER
ECONOMIZER
ENTHALPY SETPOINT =
XX.X MA
ENTHALPY SET POINT MA SETTING
73°F 12.0
70°F 13.6
67°F 15.5
63°F 17.6
FREE COOLING
SUPPLY AIR SETPOINT
= XX.X F
CLIMATE ZONE SINGLE SENSIBLE
1, 3, 5, 11-16 75.0°F
2, 4, 10 73.0°F
6, 8, 9 71.0°F
7 69.0°F
MIN DAMPER POSITION
BLOWER ON HIGH = X.X %
MIN DAMPER POSITION
BLOWER ON LOW = X.X %
DEMAND CONTROL VENT
DAMPER START OPEN = XXXX.X PPM
DEMAND CONTROL VENT
DAMPER FULL OPEN = XXXX.X PPM
DEMAND CONTROL VENT
DAMPER MAX OPENING = XXX.X%
FRESH AIR HEATING
ENABLE FAH = YES OR
NO
FRESH AIR HEATING FAH SETPOINT = XX F
FRESH AIR COOLING
ENABLE AFC = YES OR
NO
FRESH AIR COOLING AFC SETPOINT = XX F
TABLE 18
MENU INTERFACE (LEVEL 1 - SETTINGS) - D (DUAL ENTHALPY)
Level 2
Level 3
Level 4
USE THE ADJUST AND SET VALUES ARROWS TO SCROLL UP OR
DOWN FOR SELECTION OPTIONS.
RTU OPTION DAMPER
ECONOMIZER
ENTHALPY OFFSET =
X.XX MA
TEMP OFFSET* RELATIVE HUMIDITY
°F OFFSET %** MA SETTING
2 6 1.0
3.5 12 2.0
5.3 18 3.0
7 24 4.0
* AT A CONSTANT RELATIVE HUMIDITY.
** AT A CONSTANT TEMPERATURE
FREE COOLING
SUPPLY AIR SETPOINT
= XX F
CLIMATE ZONE SINGLE SENSIBLE
1, 3, 5, 11-16 75°F
2, 4, 10 73°F
6, 8, 9 71°F
7 69°F
MIN DAMPER POSITION
BLOWER ON HIGH = X.X %
MIN DAMPER POSITION
BLOWER ON LOW = X.X %
DEMAND CONTROL VENT
DAMPER START OPEN = XXXX.X PPM
DEMAND CONTROL VENT
DAMPER FULL OPEN = XXXX.X PPM
DEMAND CONTROL VENT
DAMPER MAX OPENING = XXX.X%
FRESH AIR HEATING
ENABLE FAH = YES OR
NO
FRESH AIR HEATING FAH SETPOINT = XX F
FRESH AIR COOLING
ENABLE AFC = YES OR
NO
FRESH AIR COOLING AFC SETPOINT = XX F
