Page 12
ELECTRICAL DATA 3 TON
Model No. LGM036U4E / LGM036U4P
1
Voltage - 60Hz 208/230V-3ph 460V-3ph 575V-3ph
Compressor Rated Load Amps 9.1 4.1
Outdoor Fan
Motor
Full Load Amps 2.8 1.4 1.1
Power Exhaust
(1) 0.33 HP
Full Load Amps 2.4 1.3 1
20
Indoor Blower
Motor
Horsepower
Full Load Amps 4.4 2.3 2.3
2
Maximum
Overcurrent
Protection (MOCP)
Unit Only
With (1) 0.33 HP
Power Exhaust
30
3
Minimum
Circuit
Ampacity (MCA)
Unit Only 19 11 9
With (1) 0.33 HP
Power Exhaust
21 12 10
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
ELECTRICAL DATA 4 TON
Model No. LGM048U4E / LGM048U4P
1
Voltage - 60Hz 208/230V-3ph 460V-3ph 575V-3ph
Compressor Rated Load Amps 13.8
Outdoor Fan
Motor
Full Load Amps 2.8 1.4 1.1
Power Exhaust
(1) 0.33 HP
Full Load Amps 2.4 1.3 1
20
Indoor Blower
Motor
Horsepower
Full Load Amps 4.4 2.3 2.4
2
Maximum
Overcurrent
Protection (MOCP)
Unit Only
With (1) 0.33 HP
Power Exhaust
40
3
Minimum
Circuit
Ampacity (MCA)
Unit Only 12 11
With (1) 0.33 HP
Power Exhaust
27 14 12
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
