Lennox LGM Series - Electrical Data - 17.5 Ton; Voltage & Compressor Data (17.5 Ton); Fan & Blower Data (17.5 Ton); Overcurrent Protection & Ampacity (17.5 Ton)

Page 14
LGM PARTS ARRANGEMENT
8.8.8.8
EVAPORATOR
COIL
CONDENSER
FAN
CONDENSER
COIL
COMPRESSOR
CONDENSATE
DRAIN
FILTERS (4)
20 X 20 X 2”
ECONOMIZER
(OPTIONAL)
GAS VALVE
BURNERS
COMBUSTION
AIR INDUCER
BLOWER
(DIRECT DRIVE)
TXV
UNIT
CONTROLLER
REHEAT COIL
(OPTIONAL)
COIL
GUARDS
(OPTIONAL)
IGNITON CONTROL
FIGURE 1
LGM HINGED CONTROL PANEL
T1
T34
K191
K1
A55
FIGURE 2
