Lennox LGM Series Unit Information

Page 24
INVERTER WIRE ROUTING
T61
TRANSFORMER
FL1
FILTER BOARD
L43
REACTOR
A192
INVERTER
High voltage enters
the filter board here.
High voltage enters
the compressor here.
B1
COMPRESSOR
RST
R
S
T
R
S
T
WV U
208/230V INVERTER
BOARD SHOWN
FIGURE 12
INVERTER HEAT SINK
TOP VIEW
CONTROLS /
COMPRESSOR
AREA
HEAT SINK
DIVISION PANEL
BETWEEN COMPRESSOR
AND CONDENSER SECTION
CONDENSER SECTION
FIGURE 13
