Page 40
ECONOMIZER
ECONOMIZER
(STANDARD
ECONOMIZER
SHOWN)
RETURN AIR
OPENING
UNIT
B7
DAMPER MOTOR
A2 SENSOR
(REMOTE FOR USE WITH
DDC CONTROLLED UNITS)
RT16
SENSOR
SMOKE DETECTOR
(WHEN EQUIPPED)
FIGURE 32
SENSOR LOCATION
RT17
OUTDOOR AIR SENSOR
(SECURED TO INSIDE OF
CORNER MULLION)
RT16
RETURN
AIR SENSOR
RT6
DISCHARGE
AIR SENSOR
FIGURE 33
