Lennox MCFA036S4-*P

127
24.3. Wall-Mounted and Ceiling/Floor Unit Displays
IONindicationlamp(optionalfunction):Thislampilluminateswhencleanairfeatureisactivated.
DefrostIndicationLamp(forcoolingandheatingmodelsonly):Lightsupwhentheairconditionerstartsdefrostingautomaticallyor
whenthewarmaircontrolsfeatureisactivatedinheatingoperation.
OperationIndicationLamp:Thislampilluminateswhentheairconditionerisinoperation.
TimerIndicationLamp:Lightsupduringtimeroperation.
TemperatureIndicator:Displaysthetemperaturesettingswhentheairconditionerisoperational.Alsodisplayserrorcodes.
Figure 73. Wall-Mounted Unit Display
