Lennox Prodigy 2.0 User Manual

Page 129
Page 129
Table 65. M2 ECTO to M3 Parameter Cross-Reference
ECTO
Accessible via
Settings Menu
M3 Parameter NameM3 Parameter
10.17 237 DIN_EP_PARAM_OD_CFM_TARGET Y
10.18 238 DIN_EP_PARAM_OD_CFM_CALIB Y
10.19 239 DIN_EP_PARAM_LO_OD_CFM_ALARM_STPT Y
10.20 240 DIN_EP_PARAM_HI_OD_CFM_ALARM_STPT Y
10.21 241 DIN_EP_PARAM_MAX_OD_CFM_DCV_STPT Y
10.22 242 DIN_EP_PARAM_MAX_OD_CFM_FC_STPT Y
10.23 243 DIN_EP_PARAM_LO_OD_CFM_ALARM_EVAL Y
10.24 244 DIN_EP_PARAM_HI_OD_CFM_ALARM_EVAL Y
10.25 245 DIN_EP_PARAM_OA_DMPR_ERR_ALARM_EVAL Y
10.26 246 DIN_EP_PARAM_ALTITUDE_STPT Y
10.27 247 DIN_EP_PARAM_BLOW_RAMP_RATE_STPT Y
Table 65. M3 Parameter to M2 ECTO Cross-Reference
M3 Parameter ECTO Parameter Name
Accessible via
Settings Menu
1 NONE DIN_Profile_Version = 1 N
2 NONE DIN_Current_Language Y
3 NONE DIN_System_State N
4 NONE DIN_System_State_Before_Reset N
5 0.01 DIN_Supply_VAV_Control_Mode Y
6 NONE DIN_BL_ECM_FWD_CURVED_SMK_Stg_Output Y
7 NONE DIN_BL_ECM_FWD_CURVED_HT_Stg_Output Y
8 NONE DIN_BL_ECM_FWD_CURVED_CL_Stg_Output Y
9 0.09 DIN_Min_Damper_Position_Low_BLR Y
10 0.27 DIN_BL_Speed_Free_CL_Stg_Up_Delay Y
11 NONE DIN_Enable_Field_Status_Report, Y
12 10.07 DIN_MSAV_SMK_CFM Y
13 10.05 DIN_MSAV_HT_CFM Y
14 10.02 DIN_MSAV_CL_Hi_CFM Y
15 NONE DIN_MSAV_CL_Med_CFM Y
16 NONE DIN_MSAV_CL_Med_Lo_CFM Y
17 10.01 DIN_MSAV_CL_Lo_CFM Y
18 10.06 DIN_MSAV_VT_CFM Y
19 NONE DIN_MAX_CFM_RPM Y
20 0.02 DIN_MSAV_SMK_Stg_Output N
21 0.03 DIN_MSAV_VT_Stg_Output N
22 0.04 DIN_MSAV_HT_Stg_Output N
23 0.05 DIN_MSAV_CL_Stg_1_Output N
24 0.14 DIN_MSAV_CL_Stg_2_Output N
25 0.15 DIN_MSAV_CL_Stg_3_Output N
26 0.16 DIN_MSAV_CL_Stg_4_Output N
27 0.06 DIN_MSAV_Min_Output_for_CL_VT_SMK Y
28 0.07 DIN_MSAV_Min_Output_for_HT Y
29 NONE DIN_MSAV_Min_Damper_Blower_Only Y
