Page 134
Table 65. M3 Parameter to M2 ECTO Cross-Reference
M3 Parameter
Accessible via
Settings Menu
Parameter NameECTO
202 8.05 DIN_DACC_OAT_RS_SP Y
203 8.06 DIN_DACC_OAT_RS_Proportional_Band Y
204 8.04 DIN_DACC_RAT_RS_Adjust_Band Y
205 8.02 DIN_DACC_RAT_RS_SP Y
206 8.03 DIN_DACC_RAT_RS_Proportional_Band Y
207 8.01 DIN_DACC_RS_Limit Y
208 8.14 DIN_DACH_OAT_RS_Adjust_Band Y
209 8.12 DIN_DACH_OAT_RS_SP Y
210 8.13 DIN_DACH_OAT_RS_Proportional_Band Y
211 8.04 DIN_DACH_RAT_RS_Adjust_Band Y
212 8.09 DIN_DACH_RAT_RS_SP Y
213 8.10 DIN_DACH_RAT_RS_Proportional_Band Y
214 8.08 DIN_DACH_RS_Limit Y
215 8.20 DIN_Exh_Fan_Stage1_Damper_SP Y
216 8.21 DIN_Exh_Fan_Stage1_Damper_DB Y
217 NONE DIN_Exh_Fan_Stage1_Pressure_SP Y
218 NONE DIN_Exh_Fan_Stage1_Pressure_DB Y
219 8.23 DIN_Exh_Fan_Stage2_Damper_SP Y
220 8.24 DIN_Exh_Fan_Stage2_Damper_DB Y
221 NONE DIN_Exh_Fan_Stage2_Pressure_SP Y
222 NONE DIN_Exh_Fan_Stage2_Pressure_DB Y
223 8.26 DIN_Exh_Fan_StageUp_Delay Y
224 8.22 DIN_Exh_Fan_StageDown_Delay Y
225 NONE DIN_Unit_Run_Operations N
226 NONE DIN_Disable_Lockouts N
227 NONE DIN_EnabledServices N
228 10.08 DIN_EP_PARAM_LO_SPD_CALIB Y
229 10.09 DIN_EP_PARAM_HI_SPD_CALIB Y
230 NONE DIN_EP_PARAM_MED_LO_SPD_CALIB Y
231 NONE DIN_EP_PARAM_MED_HI_SPD_CALIB Y
232 10.12 DIN_EP_PARAM_HEAT_CFM_CALIB Y
233 10.13 DIN_EP_PARAM_VEN_CFM_CALIB Y
234 10.14 DIN_EP_PARAM_LO_SUP_CFM_ALARM_STPT Y
235 10.15 DIN_EP_PARAM_LO_SUP_CFM_ALARM_EVAL Y
236 10.16 DIN_EP_PARAM_NO_AIRFLOW_ALARM_EVAL Y
237 10.17 DIN_EP_PARAM_OD_CFM_TARGET Y
238 10.18 DIN_EP_PARAM_OD_CFM_CALIB Y
239 10.19 DIN_EP_PARAM_LO_OD_CFM_ALARM_STPT Y
240 10.20 DIN_EP_PARAM_HI_OD_CFM_ALARM_STPT Y
241 10.21 DIN_EP_PARAM_MAX_OD_CFM_DCV_STPT Y
242 10.22 DIN_EP_PARAM_MAX_OD_CFM_FC_STPT Y
243 10.23 DIN_EP_PARAM_LO_OD_CFM_ALARM_EVAL Y
244 10.24 DIN_EP_PARAM_HI_OD_CFM_ALARM_EVAL Y
