Lennox SIGNATURE SLP99DFV User Manual

Page 2
Unit Dimensions - inches (mm)
AIR
EXHAUST AIR
OUTLET
COMBUSTION
AIR INTAKE
FLOW
2-1/16 (52)
GAS PIPING INLET
(Either Side)
ELECTRICAL INLET
(Either Side)
RETURN AIR
OPENING
FRONT VIEW SIDE VIEW
TOP VIEW
A
B
C
3/4
(19)
27-3/4
(705)
19-1/4
(489)
9-1/8 (232) Right
6-9/16 (167) Left
2 (51)
Either Side
33
(838)
3/4
(19)
B
Supply
Air
Supply
Air
9/16
(14)
9/16
(14)
9/16
(14)
9/16
(14)
19-7/16
(494)
3/4
(19)
CONDENSATE
TRAP CONNECTION
5
(127)
6-7/16 (163)
Either Side
9 (229)
Either Side
2-1/4
(57)
(Either Side)
1-1/2 (38)
Front Panel
Flue Condensate Trap Assembly
Furnished for external
field installation
on either side of unit.
(See installation instructions
for additional
information.)
7
(178)
Model
A
in - mm
B
in - mm
C
in - mm
SLP99DF070V36 17-1/2 - 446 16-3/8 - 416 16 - 406
SLP99DF090V36C
SLP99DF090V48C
SLP99DF090V60C
SLP99DF110V60C
21 - 553 19-7/8 - 505 19-1/2 - 495
