Lennox SIGNATURE SLP99DFV User Manual

Page 45
BLOWER DATA
SLP99DF070XV36B BLOWER PERFORMANCE (less lter)
HEATING BLOWER PERFORMANCE - 0 through 0.8 in. w.g. External Static Pressure Range
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 495 543 639 735 830 926 1022 1118
Increase (+7.5%) Heat CFM 473 516 604 691 778 866 953 1041
Default Heat CFM 450 489 568 647 726 805 884 963
Decrease (-7.5% ) Heat CFM 430 467 540 614 687 761 834 908
Decrease (-15% ) Heat CFM 410 444 512 580 649 717 785 853
COOLING BLOWER PERFORMANCE - 0 through 1.0 in. w.g. External Static Pressure Range
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 625 785 890 995 910 1075 1230 1365
Default Cool CFM 575 710 830 890 845 960 1125 1265
Decrease (-10%) Cool CFM 520 615 710 820 755 885 985 1150
BLOWER DATA
SLP99DF090XV36C BLOWER PERFORMANCE (less lter)
HEATING BLOWER PERFORMANCE - 0 through 0.8 in. w.g. External Static Pressure Range
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 710 756 848 940 1033 1125 1217 1309
Increase (+7.5%) Heat CFM 670 713 799 885 971 1057 1143 1230
Default Heat CFM 629 669 749 829 910 990 1070 1150
Decrease (-7.5% ) Heat CFM 559 599 681 763 845 927 1009 1091
Decrease (-15% ) Heat CFM 488 530 614 697 781 865 948 1032
COOLING BLOWER PERFORMANCE - 0 through 1.0 in. w.g. External Static Pressure Range
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 610 770 900 1035 920 1080 1215 1385
Default Cool CFM 545 690 805 920 835 1000 1135 1255
Decrease (-10%) Cool CFM 465 620 720 810 750 890 1025 1145
The e󰀨ect of static pressure is included in air volumes shown.
The following control congurations are available. See Installation Instructions for details and DIP switch settings.
Heat Modes Available (Heating Blower Performance Table):
Single-stage thermostat:
- 35%, 70%, 100% input (three-stage) with time delays in-between
Two-stage thermostat:
- Variable Rate Capacity Mode - furnace automatically adjusts ring rate based on rst- and second-stage cycle times.
- W1 demand at 70% input, W2 demand at 100% input. No delay between stages.
Cool Mode Available (Cooling Blower Performance Table):
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan speeds are approximately 28%, and 38%, (DIP switch selectable) of the same second-stage COOL speed position minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 250 cfm.
