Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 15
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-024-230 TXV 23,200 15.50 12.00 CH23-21 4260791
XC21-024-230 TXV 24,000 18.70 13.70 CH23-31 G61MPV-36B-045 4260863
XC21-024-230 TXV 24,000 19.00 13.70 CH23-31 G61MPV-36B-070 4260864
XC21-024-230 TXV 24,200 19.00 13.70 CH23-31 G61MPV-36B-071 4260865
XC21-024-230 TXV 24,000 19.00 14.00 CH23-31 G61MPV-36C-090 4260866
XC21-024-230 TXV 24,200 19.20 14.00 CH23-31 SL280UH070V36A 4260862
XC21-024-230 TXV 24,200 19.20 14.00 CH23-31 SL280UH070XV36A 4260955
XC21-024-230 TXV 23,800 18.50 13.50 CH23-31 SL280UH090V48B 4260976
XC21-024-230 TXV 24,200 19.00 14.00 CH23-31 SLP98UH070V36B 4260936
XC21-024-230 TXV 24,200 19.20 14.00 CH23-31 SLP98UH090V36C 4260937
XC21-024-230 TXV 23,400 15.70 12.00 CH23-31 4260792
XC21-024-230 TXV 25,600 19.70 14.20 CH23-41 G61MPV-36B-045 4260869
XC21-024-230 TXV 25,600 19.70 14.50 CH23-41 G61MPV-36B-070 4260870
XC21-024-230 TXV 25,600 20.00 14.20 CH23-41 G61MPV-36B-071 4260871
XC21-024-230 TXV 25,400 20.00 14.50 CH23-41 G61MPV-36C-090 4260872
XC21-024-230 TXV 25,600 20.20 14.50 CH23-41 SL280UH070V36A 4260867
XC21-024-230 TXV 25,600 20.20 14.50 CH23-41 SL280UH070XV36A 4260956
XC21-024-230 TXV 26,000 20.20 14.70 CH23-41 SL280UH090V36B 4260868
XC21-024-230 TXV 25,200 19.20 14.20 CH23-41 SL280UH090V48B 4260977
XC21-024-230 TXV 25,600 20.00 14.50 CH23-41 SLP98UH070V36B 4260938
XC21-024-230 TXV 25,600 20.00 14.50 CH23-41 SLP98UH090V36C 4260939
XC21-024-230 TXV 24,800 16.70 12.70 CH23-41 4260793
XC21-024-230 TXV 25,600 19.70 14.20 CH23-51 G61MPV-36B-045 4260875
XC21-024-230 TXV 25,600 20.00 14.50 CH23-51 G61MPV-36B-070 4260876
XC21-024-230 TXV 25,800 20.00 14.50 CH23-51 G61MPV-36B-071 4260877
XC21-024-230 TXV 25,600 20.00 14.50 CH23-51 G61MPV-36C-090 4260878
XC21-024-230 TXV 25,600 20.20 14.50 CH23-51 SL280UH070V36A 4260873
XC21-024-230 TXV 25,600 20.20 14.50 CH23-51 SL280UH070XV36A 4260957
XC21-024-230 TXV 26,000 20.00 14.70 CH23-51 SL280UH090V36B 4260874
XC21-024-230 TXV 25,400 19.50 14.20 CH23-51 SL280UH090V48B 4260978
XC21-024-230 TXV 25,800 20.00 14.70 CH23-51 SLP98UH070V36B 4260940
XC21-024-230 TXV 25,800 20.20 14.70 CH23-51 SLP98UH090V36C 4260941
XC21-024-230 TXV 25,000 16.70 13.00 CH23-51 4260794
XC21-024-230 TXV 25,200 20.00 14.20 CH33-19 SL280UH070V36A 4260879
XC21-024-230 TXV 25,200 20.00 14.20 CH33-19 SL280UH070XV36A 4260958
XC21-024-230 TXV 24,400 16.50 12.50 CH33-19 4260795
XC21-024-230 TXV 25,000 19.50 14.00 CH33-24/30 SL280UH070V36A 4260880
XC21-024-230 TXV 25,000 19.50 14.00 CH33-24/30 SL280UH070XV36A 4260959
XC21-024-230 TXV 24,400 16.50 12.50 CH33-24/30 4260796
XC21-024-230 TXV 25,600 19.70 14.20 CH33-25 G61MPV-36B-045 4260883
XC21-024-230 TXV 25,600 20.00 14.50 CH33-25 G61MPV-36B-070 4260884
XC21-024-230 TXV 25,600 20.00 14.20 CH33-25 G61MPV-36B-071 4260885
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
