Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 16
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-024-230 TXV 25,800 20.20 14.50 CH33-25 SL280UH070V36A 4260881
XC21-024-230 TXV 25,800 20.20 14.50 CH33-25 SL280UH070XV36A 4260960
XC21-024-230 TXV 25,800 20.00 14.50 CH33-25 SL280UH090V36B 4260882
XC21-024-230 TXV 25,200 19.20 14.20 CH33-25 SL280UH090V48B 4260979
XC21-024-230 TXV 25,600 20.00 14.50 CH33-25 SLP98UH070V36B 4260942
XC21-024-230 TXV 25,000 17.00 13.00 CH33-25A 4260797
XC21-024-230 TXV 24,800 16.70 12.70 CH33-25B 4260798
XC21-024-230 TXV 26,200 20.20 14.70 CH33-31 G61MPV-36B-045 4260888
XC21-024-230 TXV 26,200 20.50 14.70 CH33-31 G61MPV-36B-070 4260889
XC21-024-230 TXV 26,400 20.50 14.70 CH33-31 G61MPV-36B-071 4260890
XC21-024-230 TXV 26,200 20.50 14.70 CH33-31 SL280UH070V36A 4260886
XC21-024-230 TXV 26,200 20.50 14.70 CH33-31 SL280UH070XV36A 4260961
XC21-024-230 TXV 26,600 20.50 15.00 CH33-31 SL280UH090V36B 4260887
XC21-024-230 TXV 26,000 20.00 14.50 CH33-31 SL280UH090V48B 4260980
XC21-024-230 TXV 26,400 20.50 15.00 CH33-31 SLP98UH070V36B 4260943
XC21-024-230 TXV 25,600 17.20 13.20 CH33-31A 4260799
XC21-024-230 TXV 25,600 17.20 13.20 CH33-31B 4260800
XC21-024-230 TXV 25,400 19.70 14.20 CH33-36 G61MPV-36B-045 4260893
XC21-024-230 TXV 25,400 19.70 14.20 CH33-36 G61MPV-36B-070 4260894
XC21-024-230 TXV 25,600 20.00 14.20 CH33-36 G61MPV-36B-071 4260895
XC21-024-230 TXV 25,600 20.20 14.50 CH33-36 G61MPV-36C-090 4260896
XC21-024-230 TXV 25,400 20.00 14.20 CH33-36 SL280UH070V36A 4260891
XC21-024-230 TXV 25,400 20.00 14.20 CH33-36 SL280UH070XV36A 4260962
XC21-024-230 TXV 25,800 20.00 14.50 CH33-36 SL280UH090V36B 4260892
XC21-024-230 TXV 25,600 20.00 14.50 CH33-36 SLP98UH070V36B 4260944
XC21-024-230 TXV 25,800 20.20 14.70 CH33-36 SLP98UH090V36C 4260945
XC21-024-230 TXV 24,800 17.00 12.70 CH33-36A 4260801
XC21-024-230 TXV 25,200 19.20 14.20 CH33-36B SL280UH090V48B 4260981
XC21-024-230 TXV 24,800 16.70 12.70 CH33-36B 4260802
XC21-024-230 TXV 25,000 17.00 12.70 CH33-36C 4260803
XC21-024-230 TXV 26,000 20.20 14.50 CH33-42 G61MPV-36B-045 4260898
XC21-024-230 TXV 26,000 20.20 14.70 CH33-42 G61MPV-36B-070 4260899
XC21-024-230 TXV 26,200 20.20 14.50 CH33-42 G61MPV-36B-071 4260900
XC21-024-230 TXV 26,400 20.20 15.00 CH33-42 SL280UH090V36B 4260897
XC21-024-230 TXV 25,800 19.70 14.50 CH33-42 SL280UH090V48B 4260982
XC21-024-230 TXV 26,200 20.50 14.70 CH33-42 SLP98UH070V36B 4260946
XC21-024-230 TXV 25,400 17.20 13.00 CH33-42 4260804
XC21-024-230 TXV 26,600 20.50 14.70 CH33-43 G61MPV-36B-045 4260902
XC21-024-230 TXV 26,600 20.70 15.00 CH33-43 G61MPV-36B-070 4260903
XC21-024-230 TXV 26,800 20.70 15.00 CH33-43 G61MPV-36B-071 4260904
XC21-024-230 TXV 26,400 21.00 15.20 CH33-43 G61MPV-36C-090 4260905
XC21-024-230 TXV 26,800 20.70 15.20 CH33-43 SL280UH090V36B 4260901
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
