Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 17
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-024-230 TXV 26,400 20.20 14.70 CH33-43 SL280UH090V48B 4260983
XC21-024-230 TXV 26,800 20.70 15.20 CH33-43 SLP98UH070V36B 4260947
XC21-024-230 TXV 26,600 21.00 15.20 CH33-43 SLP98UH090V36C 4260948
XC21-024-230 TXV 26,000 17.50 13.20 CH33-43B 4260805
XC21-024-230 TXV 25,800 17.50 13.20 CH33-43C 4260806
XC21-024-230 TXV 24,400 18.70 13.50 CR33-24 SL280DF070V36A 4260850
XC21-024-230 TXV 24,400 18.70 13.70 CR33-24 SL280DF090V48B 4260851
XC21-024-230 TXV 23,600 16.00 12.20 CR33-24 4260789
XC21-024-230 TXV 26,000 20.20 14.50 CR33-30/36 G61MPV-36B-045 4260856
XC21-024-230 TXV 25,800 20.20 14.50 CR33-30/36 G61MPV-36B-070 4260852
XC21-024-230 TXV 26,000 20.50 14.50 CR33-30/36 G61MPV-36B-071 4260853
XC21-024-230 TXV 25,800 20.50 14.70 CR33-30/36 G61MPV-36C-090 4260857
XC21-024-230 TXV 26,200 20.20 14.50 CR33-30/36 SL280DF070V36A 4260854
XC21-024-230 TXV 26,400 20.50 14.70 CR33-30/36 SL280DF090V48B 4260855
XC21-024-230 TXV 26,000 20.20 14.70 CR33-30/36 SLP98DF070V36B 4260967
XC21-024-230 TXV 26,000 20.20 14.70 CR33-30/36 SLP98DF090V36C 4260968
XC21-024-230 TXV 25,200 17.20 13.00 CR33-30/36 4260790
XC21-024-230 TXV 24,000 18.20 13.50 CX34-18/24 CBWMV-24B-040 4260964
XC21-024-230 TXV 24,200 18.50 13.50 CX34-18/24 G61MPV-36B-045 4260814
XC21-024-230 TXV 24,200 18.50 13.50 CX34-18/24 G61MPV-36B-070 4260815
XC21-024-230 TXV 24,400 18.70 13.50 CX34-18/24 G61MPV-36B-071 4260816
XC21-024-230 TXV 24,200 18.70 13.70 CX34-18/24 G61MPV-36C-090 4260817
XC21-024-230 TXV 24,200 19.00 13.70 CX34-18/24 SL280UH070V36A 4260822
XC21-024-230 TXV 24,200 19.00 13.70 CX34-18/24 SL280UH070XV36A 4260949
XC21-024-230 TXV 24,800 19.00 13.70 CX34-18/24 SL280UH090V36B 4260823
XC21-024-230 TXV 24,000 18.00 13.50 CX34-18/24 SL280UH090V48B 4260969
XC21-024-230 TXV 24,400 18.70 13.70 CX34-18/24 SLP98UH070V36B 4260931
XC21-024-230 TXV 24,400 18.70 13.70 CX34-18/24 SLP98UH090V36C 4260925
XC21-024-230 TXV 23,600 16.00 12.20 CX34-18/24 4260782
XC21-024-230 TXV 24,800 19.50 13.50 CX34-19 O23V2/3-70/90 4260917
XC21-024-230 TXV 25,600 20.00 14.20 CX34-25 G61MPV-36B-045 4260819
XC21-024-230 TXV 25,600 20.00 14.50 CX34-25 G61MPV-36B-070 4260820
XC21-024-230 TXV 25,600 20.20 14.20 CX34-25 G61MPV-36B-071 4260821
XC21-024-230 TXV 25,200 20.00 13.70 CX34-25 O23V2/3-70/90 4260918
XC21-024-230 TXV 25,600 20.00 14.20 CX34-25 SL280UH070V36A 4260924
XC21-024-230 TXV 25,600 20.00 14.20 CX34-25 SL280UH070XV36A 4260963
XC21-024-230 TXV 26,000 20.50 14.70 CX34-25 SL280UH090V36B 4260818
XC21-024-230 TXV 25,400 19.50 14.20 CX34-25 SL280UH090V48B 4260970
XC21-024-230 TXV 25,800 20.20 14.70 CX34-25 SLP98UH070V36B 4260926
XC21-024-230 TXV 25,000 17.00 13.00 CX34-25 4260783
XC21-024-230 TXV 24,800 18.70 13.70 CX34-30 G61MPV-36B-045 4260826
XC21-024-230 TXV 24,800 19.00 13.70 CX34-30 G61MPV-36B-070 4260827
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
