Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 18
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-024-230 TXV 24,800 19.00 13.70 CX34-30 G61MPV-36B-071 4260828
XC21-024-230 TXV 24,600 19.00 14.00 CX34-30 G61MPV-36C-090 4260829
XC21-024-230 TXV 24,400 18.70 13.20 CX34-30 O23V2/3-70/90 4260919
XC21-024-230 TXV 24,800 19.20 14.00 CX34-30 SL280UH070V36A 4260824
XC21-024-230 TXV 24,800 19.20 14.00 CX34-30 SL280UH070XV36A 4260950
XC21-024-230 TXV 25,200 19.20 14.00 CX34-30 SL280UH090V36B 4260825
XC21-024-230 TXV 24,800 19.00 13.70 CX34-30 SLP98UH070V36B 4260927
XC21-024-230 TXV 24,800 19.20 14.00 CX34-30 SLP98UH090V36C 4260928
XC21-024-230 TXV 24,200 16.20 12.50 CX34-30 4260784
XC21-024-230 TXV 26,000 20.20 14.50 CX34-31 G61MPV-36B-045 4260832
XC21-024-230 TXV 26,000 20.20 14.70 CX34-31 G61MPV-36B-070 4260833
XC21-024-230 TXV 26,200 20.50 14.50 CX34-31 G61MPV-36B-071 4260834
XC21-024-230 TXV 25,800 20.20 14.20 CX34-31 O23V2/3-70/90 4260920
XC21-024-230 TXV 26,200 20.70 14.70 CX34-31 SL280UH070V36A 4260830
XC21-024-230 TXV 26,200 20.70 14.70 CX34-31 SL280UH070XV36A 4260951
XC21-024-230 TXV 26,200 20.00 14.50 CX34-31 SL280UH090V36B 4260831
XC21-024-230 TXV 25,800 19.70 14.50 CX34-31 SL280UH090V48B 4260971
XC21-024-230 TXV 26,200 20.50 14.70 CX34-31 SLP98UH070V36B 4260929
XC21-024-230 TXV 25,400 17.20 13.00 CX34-31 4260785
XC21-024-230 TXV 25,200 19.50 14.50 CX34-36 CBWMV-36B-070 4260965
XC21-024-230 TXV 25,400 19.70 14.50 CX34-36 CBWMV-36C-090 4260966
XC21-024-230 TXV 25,600 19.70 14.20 CX34-36 G61MPV-36B-045 4260837
XC21-024-230 TXV 25,400 20.00 14.20 CX34-36 G61MPV-36B-070 4260838
XC21-024-230 TXV 25,600 20.00 14.20 CX34-36 G61MPV-36B-071 4260839
XC21-024-230 TXV 25,400 20.00 14.50 CX34-36 G61MPV-36C-090 4260840
XC21-024-230 TXV 25,200 19.70 13.70 CX34-36 O23V2/3-70/90 4260921
XC21-024-230 TXV 25,600 20.20 14.50 CX34-36 SL280UH070V36A 4260835
XC21-024-230 TXV 25,600 20.20 14.50 CX34-36 SL280UH070XV36A 4260952
XC21-024-230 TXV 26,000 20.20 14.70 CX34-36 SL280UH090V36B 4260836
XC21-024-230 TXV 25,200 19.20 14.20 CX34-36 SL280UH090V48B 4260972
XC21-024-230 TXV 25,600 20.00 14.50 CX34-36 SLP98UH070V36B 4260930
XC21-024-230 TXV 25,600 20.20 14.50 CX34-36 SLP98UH090V36C 4260932
XC21-024-230 TXV 24,800 16.70 12.70 CX34-36 4260786
XC21-024-230 TXV 26,400 20.20 14.70 CX34-38 G61MPV-36B-045 4260843
XC21-024-230 TXV 26,200 20.50 14.70 CX34-38 G61MPV-36B-070 4260844
XC21-024-230 TXV 26,400 20.50 14.70 CX34-38 G61MPV-36B-071 4260845
XC21-024-230 TXV 26,000 20.20 14.20 CX34-38 O23V2/3-70/90 4260922
XC21-024-230 TXV 26,400 20.70 15.00 CX34-38 SL280UH070V36A 4260841
XC21-024-230 TXV 26,400 20.70 15.00 CX34-38 SL280UH070XV36A 4260953
XC21-024-230 TXV 26,800 20.70 15.00 CX34-38 SL280UH090V36B 4260842
XC21-024-230 TXV 26,000 20.00 14.50 CX34-38 SL280UH090V48B 4260973
XC21-024-230 TXV 26,400 20.50 15.00 CX34-38 SLP98UH070V36B 4260933
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
