Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 19
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-024-230 TXV 25,600 17.20 13.20 CX34-38 4260787
XC21-024-230 TXV 25,600 19.70 14.20 CX34-42 G61MPV-36B-045 4260847
XC21-024-230 TXV 25,400 20.00 14.20 CX34-42 G61MPV-36B-070 4260848
XC21-024-230 TXV 25,600 20.00 14.20 CX34-42 G61MPV-36B-071 4260849
XC21-024-230 TXV 25,200 19.70 13.70 CX34-42 O23V2/3-70/90 4260923
XC21-024-230 TXV 26,000 20.20 14.70 CX34-42 SL280UH090V36B 4260846
XC21-024-230 TXV 25,200 19.20 14.20 CX34-42 SL280UH090V48B 4260974
XC21-024-230 TXV 25,600 20.00 14.50 CX34-42 SLP98UH070V36B 4260934
XC21-024-230 TXV 24,800 16.70 12.70 CX34-42 4260788
XC21-036-230 TXV 35,400 18.20 12.70 C33-36 CBWMV-36B-070 4261297
XC21-036-230 TXV 35,400 18.50 13.00 C33-36 CBWMV-36C-090 4261298
XC21-036-230 TXV 35,000 18.00 12.70 C33-36 G61MPV-36B-045 4261279
XC21-036-230 TXV 35,200 18.00 12.70 C33-36 G61MPV-36B-070 4261290
XC21-036-230 TXV 35,000 18.00 12.70 C33-36 G61MPV-36B-071 4261291
XC21-036-230 TXV 35,400 18.50 13.00 C33-36 G61MPV-36C-090 4261292
XC21-036-230 TXV 35,200 18.50 13.20 C33-36 SL280UH090V36B 4261277
XC21-036-230 TXV 35,600 18.20 13.20 C33-36 SL280UH090V48B 4261278
XC21-036-230 TXV 35,600 18.20 13.20 C33-36 SL280UH090XV48B 4261296
XC21-036-230 TXV 35,000 18.20 12.70 C33-36 SLP98UH070V36B 4261293
XC21-036-230 TXV 35,600 18.50 13.00 C33-36 SLP98UH090V36C 4261294
XC21-036-230 TXV 35,400 18.20 13.20 C33-36 SLP98UH090V48C 4261295
XC21-036-230 TXV 36,000 18.70 13.00 C33-36 SLP98UH090V60C 4261299
XC21-036-230 TXV 35,800 18.70 13.20 C33-36 SLP98UH110V60C 4261300
XC21-036-230 TXV 35,000 16.20 12.00 C33-36 4261076
XC21-036-230 TXV 36,800 19.00 13.20 C33-38 CBWMV-36B-070 4261310
XC21-036-230 TXV 36,400 18.70 13.00 C33-38 G61MPV-36B-045 4261304
XC21-036-230 TXV 36,600 18.70 13.20 C33-38 G61MPV-36B-070 4261305
XC21-036-230 TXV 36,400 18.70 13.00 C33-38 G61MPV-36B-071 4261306
XC21-036-230 TXV 36,800 19.00 13.20 C33-38 SL280UH070V36A 4261301
XC21-036-230 TXV 36,800 19.00 13.20 C33-38 SL280UH070XV36A 4261308
XC21-036-230 TXV 36,600 19.20 13.50 C33-38 SL280UH090V36B 4261302
XC21-036-230 TXV 37,000 19.00 13.50 C33-38 SL280UH090V48B 4261303
XC21-036-230 TXV 37,000 19.00 13.50 C33-38 SL280UH090XV48B 4261309
XC21-036-230 TXV 36,600 19.00 13.20 C33-38 SLP98UH070V36B 4261307
XC21-036-230 TXV 36,400 16.70 12.50 C33-38 4261077
XC21-036-230 TXV 35,400 18.20 12.70 C33-42 CBWMV-36B-070 4261318
XC21-036-230 TXV 35,000 18.00 12.70 C33-42 G61MPV-36B-045 4261313
XC21-036-230 TXV 35,200 18.00 12.70 C33-42 G61MPV-36B-070 4261314
XC21-036-230 TXV 35,000 18.00 12.70 C33-42 G61MPV-36B-071 4261315
XC21-036-230 TXV 35,200 18.50 13.20 C33-42 SL280UH090V36B 4261311
XC21-036-230 TXV 35,600 18.20 13.20 C33-42 SL280UH090V48B 4261312
XC21-036-230 TXV 35,600 18.20 13.20 C33-42 SL280UH090XV48B 4261317
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
