Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 26
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-036-230 TXV 37,400 19.70 13.70 CX34-49 SL28UH090V60C 4261187
XC21-036-230 TXV 36,800 19.00 13.50 CX34-49 SLP98UH090V36C 4261196
XC21-036-230 TXV 37,200 19.00 13.70 CX34-49 SLP98UH090V48C 4261197
XC21-036-230 TXV 36,800 16.70 12.50 CX34-49 4261058
XC21-036-230 TXV 36,600 19.00 13.50 CX34-50/60C G61MPV-36C-090 4261122
XC21-036-230 TXV 36,400 19.00 13.50 CX34-50/60C SLP98UH090V36C 4261198
XC21-036-230 TXV 36,800 19.00 13.50 CX34-50/60C SLP98UH090V48C 4261199
XC21-036-230 TXV 36,400 16.70 12.50 CX34-50/60C 4261059
XC21-036-230 TXV 37,000 18.50 13.00 CX34-60D O23V3/4-105/120 4261186
XC21-036-230 TXV 37,400 19.50 13.70 CX34-60D SL280UH135V60D 4261123
XC21-036-230 TXV 36,800 16.70 12.50 CX34-60D 4261060
XC21-048-230 TXV 49,000 17.50 13.00 C33-43 G61MPV-60C-090 4261636
XC21-048-230 TXV 49,000 17.20 12.70 C33-43 G61MPV-60C-091 4261637
XC21-048-230 TXV 49,000 17.50 13.00 C33-43 G61MPV-60C-110 4261638
XC21-048-230 TXV 49,000 17.50 13.00 C33-43 G61MPV-60C-111 4261640
XC21-048-230 TXV 49,000 17.20 13.00 C33-43 SL280UH090V48B 4261643
XC21-048-230 TXV 49,000 17.70 13.00 C33-43 SL280UH090V60C 4261641
XC21-048-230 TXV 49,000 17.20 13.00 C33-43 SL280UH090XV48B 4261648
XC21-048-230 TXV 49,000 17.70 13.00 C33-43 SL280UH090XV60C 4261651
XC21-048-230 TXV 49,000 17.50 13.20 C33-43 SL280UH110V60C 4261634
XC21-048-230 TXV 49,000 17.50 13.20 C33-43 SL280UH110XV60C 4261650
XC21-048-230 TXV 49,000 17.50 13.00 C33-43 SLP98UH090V48C 4261644
XC21-048-230 TXV 49,000 17.50 13.00 C33-43 SLP98UH090V60C 4261645
XC21-048-230 TXV 49,000 17.50 13.00 C33-43 SLP98UH110V60C 4261647
XC21-048-230 TXV 48,500 16.00 12.50 C33-43 4261386
XC21-048-230 TXV 48,500 17.00 12.70 C33-48 CBWMV-60C-100 4261669
XC21-048-230 TXV 48,500 17.00 12.70 C33-48 CBWMV-60C-120 4261670
XC21-048-230 TXV 48,500 17.00 12.70 C33-48 G61MPV-60C-090 4261655
XC21-048-230 TXV 48,500 16.70 12.50 C33-48 G61MPV-60C-091 4261656
XC21-048-230 TXV 48,500 17.00 12.70 C33-48 G61MPV-60C-110 4261658
XC21-048-230 TXV 48,500 17.00 12.70 C33-48 G61MPV-60C-111 4261659
XC21-048-230 TXV 48,000 17.00 12.70 C33-48 SL280UH090V48B 4261660
XC21-048-230 TXV 48,500 17.20 13.00 C33-48 SL280UH090V60C 4261652
XC21-048-230 TXV 48,000 17.00 12.70 C33-48 SL280UH090XV48B 4261666
XC21-048-230 TXV 48,500 17.20 13.00 C33-48 SL280UH090XV60C 4261672
XC21-048-230 TXV 48,500 17.00 13.00 C33-48 SL280UH110V60C 4261654
XC21-048-230 TXV 48,500 17.00 13.00 C33-48 SL280UH110XV60C 4261667
XC21-048-230 TXV 48,500 17.00 12.70 C33-48 SLP98UH090V48C 4261663
XC21-048-230 TXV 48,500 17.00 12.70 C33-48 SLP98UH090V60C 4261662
XC21-048-230 TXV 48,500 17.00 12.70 C33-48 SLP98UH110V60C 4261665
XC21-048-230 TXV 48,000 15.70 12.20 C33-48 4261387
XC21-048-230 TXV 50,000 17.50 13.20 C33-49 CBWMV-60C-100 4261684
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
