Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 27
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-048-230 TXV 49,500 17.50 13.00 C33-49 CBWMV-60C-120 4261686
XC21-048-230 TXV 49,500 17.50 13.00 C33-49 G61MPV-60C-090 4261674
XC21-048-230 TXV 49,500 17.20 12.70 C33-49 G61MPV-60C-091 4261676
XC21-048-230 TXV 50,000 17.50 13.20 C33-49 G61MPV-60C-110 4261677
XC21-048-230 TXV 50,000 17.50 13.20 C33-49 G61MPV-60C-111 4261678
XC21-048-230 TXV 49,500 17.70 13.20 C33-49 SL280UH090V60C 4261723
XC21-048-230 TXV 49,500 17.70 13.20 C33-49 SL280UH090XV60C 4261687
XC21-048-230 TXV 49,500 17.50 13.20 C33-49 SL280UH110V60C 4261673
XC21-048-230 TXV 49,500 17.50 13.20 C33-49 SL280UH110XV60C 4261683
XC21-048-230 TXV 49,500 17.50 13.00 C33-49 SLP98UH090V48C 4261681
XC21-048-230 TXV 49,500 17.50 13.00 C33-49 SLP98UH090V60C 4261680
XC21-048-230 TXV 50,000 17.50 13.20 C33-49 SLP98UH110V60C 4261682
XC21-048-230 TXV 49,500 16.00 12.70 C33-49 4261388
XC21-048-230 TXV 49,000 17.20 13.00 C33-50/60C CBWMV-60C-100 4261625
XC21-048-230 TXV 48,500 17.00 12.70 C33-50/60C CBWMV-60C-120 4261626
XC21-048-230 TXV 49,000 17.20 12.70 C33-50/60C G61MPV-60C-090 4261691
XC21-048-230 TXV 49,000 17.00 12.70 C33-50/60C G61MPV-60C-091 4261692
XC21-048-230 TXV 49,000 17.20 12.70 C33-50/60C G61MPV-60C-110 4261694
XC21-048-230 TXV 49,000 17.20 12.70 C33-50/60C G61MPV-60C-111 4261695
XC21-048-230 TXV 49,000 17.50 13.00 C33-50/60C SL280UH090V60C 4261688
XC21-048-230 TXV 49,000 17.50 13.00 C33-50/60C SL280UH090XV60C 4261628
XC21-048-230 TXV 48,500 17.20 12.70 C33-50/60C SL280UH110V60C 4261690
XC21-048-230 TXV 48,500 17.20 12.70 C33-50/60C SL280UH110XV60C 4261624
XC21-048-230 TXV 48,500 17.20 12.70 C33-50/60C SLP98UH090V48C 4261698
XC21-048-230 TXV 49,000 17.20 12.70 C33-50/60C SLP98UH090V60C 4261696
XC21-048-230 TXV 49,000 17.20 12.70 C33-50/60C SLP98UH110V60C 4261699
XC21-048-230 TXV 48,500 15.70 12.50 C33-50/60C 4261390
XC21-048-230 TXV 49,500 17.50 13.00 C33-60D G61MPV-60D-135 4261630
XC21-048-230 TXV 49,500 17.70 13.20 C33-60D SL280UH135V60D 4261629
XC21-048-230 TXV 49,500 17.50 13.00 C33-60D SLP98UH135V60D 4261632
XC21-048-230 TXV 49,500 16.00 12.70 C33-60D 4261383
XC21-048-230 TXV 51,000 18.20 13.50 C33-62C CBWMV-60C-100 4261714
XC21-048-230 TXV 50,500 18.00 13.20 C33-62C CBWMV-60C-120 4261715
XC21-048-230 TXV 51,000 18.00 13.20 C33-62C G61MPV-60C-090 4261703
XC21-048-230 TXV 51,000 18.00 13.20 C33-62C G61MPV-60C-091 4261705
XC21-048-230 TXV 51,000 18.20 13.20 C33-62C G61MPV-60C-110 4261706
XC21-048-230 TXV 51,000 18.00 13.50 C33-62C G61MPV-60C-111 4261707
XC21-048-230 TXV 50,500 17.70 13.00 C33-62C O23V5-140/154 4261633
XC21-048-230 TXV 51,000 18.20 13.50 C33-62C SL280UH090V60C 4261701
XC21-048-230 TXV 51,000 18.20 13.50 C33-62C SL280UH090XV60C 4261717
XC21-048-230 TXV 51,000 18.20 13.50 C33-62C SL280UH110V60C 4261702
XC21-048-230 TXV 51,000 18.20 13.50 C33-62C SL280UH110XV60C 4261713
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
