Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 28
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-048-230 TXV 51,000 18.20 13.50 C33-62C SLP98UH090V48C 4261710
XC21-048-230 TXV 51,000 18.20 13.50 C33-62C SLP98UH090V60C 4261709
XC21-048-230 TXV 51,000 18.20 13.20 C33-62C SLP98UH110V60C 4261711
XC21-048-230 TXV 50,500 16.50 12.70 C33-62C 4261384
XC21-048-230 TXV 50,500 17.70 13.50 C33-62D G61MPV-60D-135 4261719
XC21-048-230 TXV 50,000 17.70 12.70 C33-62D O23V5-140/154 4261721
XC21-048-230 TXV 50,500 17.70 13.50 C33-62D SL280UH135V60D 4261718
XC21-048-230 TXV 50,500 17.70 13.50 C33-62D SLP98UH135V60D 4261722
XC21-048-230 TXV 50,000 16.20 12.70 C33-62D 4261391
XC21-048-230 TXV 49,500 18.00 13.20 CBX27UH-048 4261510
XC21-048-230 TXV 49,000 17.70 13.20 CBX27UH-060 4261520
XC21-048-230 TXV 49,000 16.70 12.70 CBX32M-048 4261511
XC21-048-230 TXV 46,500 17.00 12.00 CBX32MV-036 4261517
XC21-048-230 TXV 49,500 18.00 13.20 CBX32MV-048 4261512
XC21-048-230 TXV 50,000 18.00 13.20 CBX32MV-060 4261514
XC21-048-230 TXV 49,500 17.70 13.20 CBX32MV-068 4261515
XC21-048-230 TXV 47,000 17.00 12.20 CBX40UHV-036 4261516
XC21-048-230 TXV 49,500 18.00 13.00 CBX40UHV-048 4261393
XC21-048-230 TXV 49,500 18.00 13.00 CBX40UHV-060 4261394
XC21-048-230 TXV 47,000 15.20 12.00 CH23-41 4261368
XC21-048-230 TXV 47,500 17.00 12.50 CH23-51 G61MPV-60C-090 4261444
XC21-048-230 TXV 47,500 16.70 12.20 CH23-51 G61MPV-60C-091 4261447
XC21-048-230 TXV 48,000 17.00 12.70 CH23-51 G61MPV-60C-110 4261446
XC21-048-230 TXV 48,000 17.00 12.70 CH23-51 G61MPV-60C-111 4261448
XC21-048-230 TXV 48,000 17.00 12.70 CH23-51 G61MPV-60D-135 4261449
XC21-048-230 TXV 48,000 17.00 12.70 CH23-51 SL280UH090V60C 4261440
XC21-048-230 TXV 48,000 17.00 12.70 CH23-51 SL280UH090XV60C 4261613
XC21-048-230 TXV 47,500 17.00 12.70 CH23-51 SL280UH110V60C 4261441
XC21-048-230 TXV 47,500 17.00 12.70 CH23-51 SL280UH110XV60C 4261585
XC21-048-230 TXV 48,000 17.00 12.70 CH23-51 SL280UH135V60D 4261443
XC21-048-230 TXV 48,000 17.00 12.70 CH23-51 SLP98UH090V60C 4261548
XC21-048-230 TXV 47,500 17.20 12.70 CH23-51 SLP98UH110V60C 4261549
XC21-048-230 TXV 48,000 17.00 13.00 CH23-51 SLP98UH135V60D 4261551
XC21-048-230 TXV 47,500 15.50 12.20 CH23-51 4261369
XC21-048-230 TXV 48,500 17.20 13.00 CH23-65 G61MPV-60C-090 4261455
XC21-048-230 TXV 48,500 17.20 12.70 CH23-65 G61MPV-60C-091 4261457
XC21-048-230 TXV 48,500 17.50 13.00 CH23-65 G61MPV-60C-110 4261456
XC21-048-230 TXV 48,500 17.50 13.00 CH23-65 G61MPV-60C-111 4261459
XC21-048-230 TXV 48,500 17.50 13.00 CH23-65 G61MPV-60D-135 4261460
XC21-048-230 TXV 48,500 17.70 13.00 CH23-65 SL280UH090V60C 4261451
XC21-048-230 TXV 48,500 17.70 13.00 CH23-65 SL280UH090XV60C 4261614
XC21-048-230 TXV 48,500 17.50 13.20 CH23-65 SL280UH110V60C 4261452
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
