XC21 - 2 to 5 Ton Air Conditioner / Page 29
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-048-230 TXV 48,500 17.50 13.20 CH23-65 SL280UH110XV60C 4261587
XC21-048-230 TXV 48,500 17.70 13.00 CH23-65 SL280UH135V60D 4261453
XC21-048-230 TXV 48,500 17.50 13.00 CH23-65 SLP98UH090V60C 4261552
XC21-048-230 TXV 48,500 17.50 13.00 CH23-65 SLP98UH110V60C 4261553
XC21-048-230 TXV 48,500 17.50 13.00 CH23-65 SLP98UH135V60D 4261555
XC21-048-230 TXV 48,000 15.50 12.20 CH23-65 4261371
XC21-048-230 TXV 50,500 18.00 13.50 CH23-68 G61MPV-60C-090 4261464
XC21-048-230 TXV 50,500 17.70 13.20 CH23-68 G61MPV-60C-091 4261467
XC21-048-230 TXV 50,500 18.20 13.50 CH23-68 G61MPV-60C-110 4261465
XC21-048-230 TXV 50,500 18.00 13.50 CH23-68 G61MPV-60C-111 4261468
XC21-048-230 TXV 50,500 18.00 13.50 CH23-68 G61MPV-60D-135 4261471
XC21-048-230 TXV 50,500 18.20 13.50 CH23-68 SL280UH090V60C 4261461
XC21-048-230 TXV 50,500 18.20 13.50 CH23-68 SL280UH090XV60C 4261616
XC21-048-230 TXV 50,500 18.20 13.50 CH23-68 SL280UH110V60C 4261463
XC21-048-230 TXV 50,500 18.20 13.50 CH23-68 SL280UH110XV60C 4261588
XC21-048-230 TXV 50,500 18.20 13.50 CH23-68 SL280UH135V60D 4261469
XC21-048-230 TXV 50,500 18.00 13.50 CH23-68 SLP98UH090V60C 4261556
XC21-048-230 TXV 50,500 18.20 13.50 CH23-68 SLP98UH110V60C 4261557
XC21-048-230 TXV 50,500 18.00 13.50 CH23-68 SLP98UH135V60D 4261559
XC21-048-230 TXV 50,000 16.20 12.70 CH23-68 4261372
XC21-048-230 TXV 50,000 17.50 13.00 CH33-43 SL280UH090V48B 4261524
XC21-048-230 TXV 50,000 17.50 13.00 CH33-43 SL280UH090XV48B 4261578
XC21-048-230 TXV 49,000 16.00 12.50 CH33-43 4261374
XC21-048-230 TXV 48,500 16.70 12.70 CH33-44/48 SL280UH090V48B 4261525
XC21-048-230 TXV 48,500 16.70 12.70 CH33-44/48 SL280UH090XV48B 4261579
XC21-048-230 TXV 49,000 17.20 12.70 CH33-48 G61MPV-60C-090 4261474
XC21-048-230 TXV 49,000 17.20 12.70 CH33-48 G61MPV-60C-091 4261475
XC21-048-230 TXV 49,000 17.20 12.70 CH33-48 G61MPV-60C-110 4261476
XC21-048-230 TXV 49,000 17.20 12.70 CH33-48 G61MPV-60C-111 4261478
XC21-048-230 TXV 49,000 17.50 13.00 CH33-48 SL280UH090V60C 4261472
XC21-048-230 TXV 49,000 17.50 13.00 CH33-48 SL280UH090XV60C 4261617
XC21-048-230 TXV 49,000 17.20 13.00 CH33-48 SL280UH110V60C 4261473
XC21-048-230 TXV 49,000 17.20 13.00 CH33-48 SL280UH110XV60C 4261590
XC21-048-230 TXV 49,000 17.20 12.70 CH33-48 SLP98UH090V48C 4261562
XC21-048-230 TXV 49,000 17.20 12.70 CH33-48 SLP98UH090V60C 4261560
XC21-048-230 TXV 49,000 17.20 12.70 CH33-48 SLP98UH110V60C 4261563
XC21-048-230 TXV 49,000 16.00 12.50 CH33-48 4261375
XC21-048-230 TXV 50,000 17.70 13.00 CH33-49 G61MPV-60C-090 4261481
XC21-048-230 TXV 50,000 17.50 12.70 CH33-49 G61MPV-60C-091 4261483
XC21-048-230 TXV 50,000 17.70 13.00 CH33-49 G61MPV-60C-110 4261484
XC21-048-230 TXV 50,000 17.50 13.00 CH33-49 G61MPV-60C-111 4261485
XC21-048-230 TXV 50,000 17.70 13.20 CH33-49 SL280UH090V60C 4261479
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.
