9. Install the new optical drive.
(1) Connect the new optical drive to the cover.
(2) Screw back the metal bracket to the new optical drive.
(3) Slide the new optical drive into the drive bay.
10. Screw the new optical drive back to the chassis.
Removing the computer cover
To remove the computer cover:
Note
For this procedure, it helps to place the computer face-down on a
soft flat surface. Lenovo recommends that you use a blanket, towel,
or other soft cloth to protect the screen surface from scratches or
other damage.
1. Remove any media (diskettes, CDs, or memory cards) from the drives,
shut down the operating system, turn off all attached devices, and the
computer.
2. Unplug all power cords from electrical outlets.
