Chapter 8. Replacing hardware
41
4. Lift up the motherboard cover.
Replacing the heatsink
To remove the heatsink:
1. Removing the computer stand. Refer to “Removing the computer stand”.
2. Removing the computer cover. Refer to “Removing the computer
cover”.
3. Removing the motherboard cover. Refer to “Removing the
motherboard cover”.
4. Remove the 4 screws that secure the heatsink to the chassis.
