Lenovo IdeaCentre B310 - Replacing the Camera

Hardware Maintenance Manual
52
4. Lift up the shell.
Replacing the camera
To replace the camera
1. Remove the computer stand. Refer to “Removing the computer stand”.
2. Remove the computer cover. Refer to “Removing the computer cover”.
3. Remove the shell. Refer to “Removing the shell”
4. Pull the pins to each side to release the camera.
5. Lift out the camera.
