Lenovo IdeaCentre K430 - Page 46

41
User Guide
Front panel connector Front USB connector
Front USB connector Mode switch connector
Serial (COM2) connector Battery
Front audio connector PCI express X 1 adapter slots (2)
System fan header
Lenovo K410
1 2 3 4 5
6
7
8
9
10 11 1214 131617 151819
20
12V power connector Microprocessor and heat sink
Microprocessor fan header Memory slots (2)
Thermal sensor header Power connector
Battery SATA connectors (3)
