42
User Guide
eSATA connector Power fan header
Front panel connector Clear CMOS jumper
Front USB connectors (2) Mini PCI-E slot
Mode switch connector Serial (COM2) connector
PCI express X 1 adapter slots (3) Front audio connector
PCI express X 16 adapter slot System fan header
Lenovo K415
1 2 3 4 5 6
7
8
9
10
11
12
14
13
1516171819202122232425
12V power connector Battery
Microprocessor and heat sink Microprocessor fan header
Memory slots (4) Thermal sensor header
