LenovoTAB37PlusHardwareMaintenanceManual
30
Figure2.Removalstepsofbattery(continued)
UseaPhillipsscrewdriverremovethetwoscrewskeepingthemetalclaspin
place,andthenremovethemetalclasp.
UsetweezerstogentlypryaparttheB2Bconnectoronthemainboard.
Step Screw (quantity) Color Torque
M1.4X2.4(2) Silver 0.7N
1
