Lenovo TAB3 7 Plus - 1080 Main Board

LenovoTAB37PlusHardwareMaintenanceManual
40
1080 Main Board
Foraccess,removetheseFRUsinorder:
• “1010BackCover”onpage 27
• “1020Battery”onpage 29
• “1030SubBoardandRFWire”onpage 32
• “1040SIMCardHolderFPC”onpage 33
• “1050USBBoardandSpeakerBox”onpage 34
• “1060MainFPC”onpage 36
• “1070Camera”onpage 38
Figure8.Removalstepsofmainboard
Usetweezerstocarefullypryoutthemotor.
Important notices for handling the main board:
Whenhandlingthemainboard,bearthefollowinginmind.
• Becarefulnottodropthemainboardonabenchtopthathasahard
surface,suchasmetal,wood,orcomposite.
• Avoidroughhandlingofanykind.
• Throughouttheprocess,makesurenottodroporstackthemainboard.
• Ifyouputthemainboarddown,makesuretoputitonlyonapadded
surfacesuchasanESDmatorconductivecorrugatedmaterial.
