Lenovo TAB3 7 Plus - Page 39

LenovoTAB37Plus
35
Figure5.RemovalstepsofUSBboardandspeaker(continued)
UseaPhillipsscrewdrivertounscrewthetwoscrewsholdingdowntheUSB
miniboard.
RemovetheUSBminiboardandspeakerbracketcomponents.
Note:IfyouneedtoremovethespeakerbracketcomponentsandUSBminiboard,usethe
solderiron
toremovetheUSBminiboardfromthespeakerbracketcomponentsandthen
removethemainwire.
Removethesiliconmicrophonesideplug(theWi‐Fiboarddoesnothavea
siliconmicrophonesideplug).
Step Screw (quantity) Color Torque
M1.4*3.5(2) Silver 0.7N
1
