Lenovo ThinkCentre Tiny-in-One 24 User Manual

Table 2-2. OSD functions
OSD Icon on Main
Menu
Submenu
Description
Options
Information
Shows resolution, refresh rate, and product details.
Note: This screen does not allow any changes to the settings.
This section lists the languages supported by your monitor.
Options
Language
Note: The language chosen only affects the language of the OSD. It has
no effect on any software running on the computer.
Options
Menu position adjusts menu location on the screen.
Menu Position
Default
Custom
Returns the menu position to the default settings.
● Horizontal: Changes the horizontal position of the OSD
● Vertical: Changes the vertical position of the OSD.
● Save
Options
Factory Default
Resets monitor to the original factory settings.
● Cancel
● Reset
Options
Accessibility
Controls button and menu settings for accessibility preferences.
Button repeat rate:
Select or to change.
● Off
● Default
● Slow
Menu time out: Sets the length of time the
OSD will remain active after the last time a button is pressed.
Exit
Exit the main menu
Chapter 2 Adjusting and using your monitor 15

Lenovo ThinkCentre Tiny-in-One 24 Specifications

General

3D	No
Color gamut	72 %
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Display surface	Matt
Display diagonal	23.8 \
Native aspect ratio	16:9
Viewable size diagonal	604.7 mm
Viewable size, vertical	313 mm
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	535 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 350, 640 x 480 (VGA), 720 x 400, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1280 x 800, 1366 x 768, 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
On/off switch	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	35 W
Power consumption (typical)	16.7 W
Certification	China RoHS, China Energy Efficiency Standard Tier 1, RoHS EU, RoHS (Turkey), EPEAT Gold, Energy Star 7.0, RoHS Ukraine
Product color	Black
Market positioning	Business
RMS rated power	1.5 W
Number of speakers	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 35 °
Number of OSD languages	8
Panel mounting interface	100 x 100 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	251.4 mm
Height (with stand)	385.08 mm
Weight (with stand)	5570 g
Depth (without stand)	68.2 mm
Width (without stand)	539.6 mm
Height (without stand)	346.45 mm
Weight (without stand)	- g
