Lenovo ThinkPad Edge E525 Hardware Maintenance Manual

Rearview
1
2
3
4
5
7
6
8
1Sleep(standby)statusindicator
1
5eSATA/USBconnector
2MediaCardReaderslot6USBconnectors
3Comboaudiojack
7Externalmonitorconnector
4HDMIport
8RJ-45(Ethernet)connector
1
:Forthedescriptionofthesleep(standby)statusindicator,seeChapter5“Statusindicators”onpage49.
Bottomview
1
2
3
4
1Batterypack3Bottomslotcover
1
2Batterypacklatch4Built-instereospeakers
1
:Thememorymodules,harddiskdrive,andwirelessLAN/WANcardsarelocatedunderneaththe
bottomslotcover.
102HardwareMaintenanceManual
Downloaded from LpManual.com Manuals

Lenovo ThinkPad Edge E525 Specifications

General

Brand	Lenovo
Model	ThinkPad Edge E525
Category	Laptop
Language	English
