StepScrewcapScrew(quantity)Color
Torque
1
M2.5×6mm,wafer-head,nylon-coated(4)
Black0.392Nm
(4kgfcm)
Wheninstalling:Makesurethatallthelatchesareattachedrmly.Thensecurethebezelwiththescrews.
2020Integratedcamera
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1030Opticaldriveortravelcover”onpage60
•“1040Bottomslotcover”onpage61
•“1070PCIExpressMiniCardforwirelessLAN”onpage64
•“1080PCIExpressMiniCardforwirelessWANforThinkPadEdgeE520models”onpage66
•“1080mSATAsolidstatedriveforThinkPadEdgeE520models”onpage67
•“1110Keyboard”onpage69
•“1120Topcaseassembly”onpage71
•“1190LCDunit”onpage89
•“2010LCDbezelassembly”onpage91
Removalstepsofintegratedcamera
