1180DC-insubcardandbasecoverassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1020ExpressCardblankbezel”onpage59
•“1030Opticaldriveortravelcover”onpage60
•“1040Bottomslotcover”onpage61
•“1060Harddiskdriveassembly”onpage63
•“1070PCIExpressMiniCardforwirelessLAN”onpage64
•“1080PCIExpressMiniCardforwirelessWANforThinkPadEdgeE520models”onpage66
•“1080mSATAsolidstatedriveforThinkPadEdgeE520models”onpage67
•“1090Backupbattery”onpage68
•“1110Keyboard”onpage69
•“1120Topcaseassembly”onpage71
•“1130Bluetoothdaughtercard”onpage74
•“1140Expresssubcard”onpage75
•“1150Speakerassembly”onpage76
•“1160Systemboardassemblyandfanassembly”onpage77
RemovalstepsofDC-insubcard
StepScrew(quantity)Color
Torque
1
M2×6mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgfcm)
Chapter8.RemovingandreplacingaFRU85
