StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgfcm)
1090Backupbattery
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1040Bottomslotcover”onpage61
Removalstepsofbackupbattery
DANGER
Useonlythebatteryspeciedinthepartslistforyourcomputer.Anyotherbatterycouldignite
orexplode.
Releasethecablefromthecableguideofthebackupbatteryasshowninthedirectionofarrow2.
Note:Yourmodelsmaylookslightlydifferentfromtheillustrationabove.
