Lenovo ThinkPad Edge E525 Hardware Maintenance Manual

Wheninstalling:Makesurethattheconnectorisattachedrmly.
2030LCDpanel,LCDcable,LCDrearcoverassembly,andhinges
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1030Opticaldriveortravelcover”onpage60
•“1040Bottomslotcover”onpage61
•“1070PCIExpressMiniCardforwirelessLAN”onpage64
•“1080PCIExpressMiniCardforwirelessWANforThinkPadEdgeE520models”onpage66
•“1080mSATAsolidstatedriveforThinkPadEdgeE520models”onpage67
•“1110Keyboard”onpage69
•“1120Topcaseassembly”onpage71
•“1190LCDunit”onpage89
•“2010LCDbezelassembly”onpage91
•“2020Integratedcamera”onpage92
RemovalstepsofLCDpanel,LCDcable,andLCDrearcoverassembly
ForThinkPadEdgeE520models
1
1
2
2
2
2
ForThinkPadEdgeE525models
Chapter8.RemovingandreplacingaFRU93
