•“1010Batterypack”onpage58
•“1040Bottomslotcover”onpage61
RemovalstepsofPCIExpressMiniCardforwirelessLAN
Instep1,unplugthejacksbyusingtheremovaltoolantennaRFconnector(P/N:08K7159)orpickthe
connectorswithyourngersandgentlyunplugtheminthedirectionofthearrow.
Note:Somemodelsmighthaveathirdwhiteantennacable.
Note:Yourmodelsmaylookslightlydifferentfromtheillustrationabove.
StepScrew(quantity)Color
Torque
2
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgfcm)
Wheninstalling:PlugthegraycableintothejackmarkedMAINorM,andtheblackcableintothejack
markedAUXorAonthecard.
Chapter8.RemovingandreplacingaFRU65
